PARTS INFORMATION
[email protected]
ECS-3351
Page 16
HANDLES • FIGURE 12
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
12-1 99414050251 SCREW,5X25 1
12-5 99178050010 NUT,LOCK 5 1
12-6 99414050401 SCREW,5X40/S 1
12-8 99200050011 WASHER,SMALL,5 1
12-9 27532710201 COLLAR,DAMPER,A 1
12-10 21932750200 DAMPER,A 2
12-11 99178050010 NUT,LOCK 5 1
12-16 0113290180 HANDLE,REAR B 1
12-17 72532161202 CAP,PUSH PIN 1
12-18 06632300201 SPRING,STOPPER 1
12-20 06433225200 PIN,PUSH 1
12-26 2573290020 LEVER,SAFETY 1
12-27 0603290020 LEVER,THROTTLE 1
12-28 06132750201 SPRING,THROTTLE LEVER 1
12-32 99101040011 NUT,4 5
12-33 0103275081 HANDLE,REAR,A 1
12-36 99416040226 SCREW,WS,4X22 5
12-41 20932750801 HANDLE,FRONT 1
12-42 26632750200 DAMPER,B 3
12-43 27632710201 COLLAR,DAMPER B 3
12-46 99073050354 SCREW,TAPPING,5X35 1
12-49 99073050354 SCREW,TAPPING,5X35 2
