8GB~32GB ExpressCard34 SSD
Transcend Information Inc.
V1.0
3
Pinouts
Pin No. Pin Name
01 GND
02 USBD-
03 USBD+
04 GND
05 NC
06 NC
07 NC
08 NC
09 NC
10 NC
11 NC
12 NC
13 NC
14 3.3V
15 3.3V
16 NC
17 NC
18 NC
19 NC
20 GND
21 NC
22 NC
23 GND
24 NC
25 NC
26 GND
Pin Identification
Symbol Function
USBD+
USBD-
USB serial data interface
3.3V Primary voltage source
GND Ground
NC No
connect
