6 Service Parts List
Specifications subject to change without notice.
Item Part No. Description
4025076 FAN, MOTORIZED IMPELLER, PROCESS AIR
2 4025224 CAPACITOR, RUN, 5 MFD, 370V, DRY, PROCESS AIR
3 4026784 COLLAR, SHORT 6” REACTIVATION DUCT (2 PLACES)
4 402635 FILTER, AIR, 2 x 2 x , REACTIVATION AIR
5 4026798 FAN, MOTORIZED IMPELLER, REACTIVATION AIR
6 4026799 HEATER CORE, PHx D385
7 4026777 TOP COVER, DESICCANT 385
8 4926898 THERMAL OVERLOAD CUT-OUT SWITCH, PROCESS AIR
9 4026830 CAPACITOR, RUN, 8 MFD, DRY, REACTIVATION AIR
0 97000 CONTROL RELAY SPST 0VAC COIL 25AMP CONTACTS
4026773 MOTOR, DESICCANT WHEEL
2 4026795 BELT, DRIVE, PHOENIx DESICCANT
3 4026772 WHEEL, DESICCANT
4 4026866 THERMAL OVERLOAD CUT-OUT SWITCH, REACTIVATION AIR
5 402475 FILTER, AIR, 6 x 20 x 2, PROCESS AIR
6 402694 SWITCH, ROCKER, DPST, ON-OFF
7 4025043 PLATE, SKID
8 4026304 WHEEL, PU 2.00, GRAY (2 PLACES)
9 4024078 COLLAR, DUCT, WIRE, 5.75 x 2.00
1
2
3
4
9
10
11
12
15
16
17
19
5
6
14
13
7
8
18
Item Part No. Description
Not 4025078 CORD, 4/3. SjT, 5V
Shown W/PLUG 25’ (2 PLACES)
Not 4026922 GASKET AND BELT
Shown REPLACEMENT KIT
