PENRIL MODEM FAMILY: Alliance / Datalink Series
V.34M/33.6, V.32M/19.2, V.32M/14.4 PRODUCT SPECIFICATIONS
Raymar Information Technology, Inc., 7325 Roseville Road, Sacramento, CA 95842
1-800-695-1951 fax 1-916-783-1952 [email protected] www.raymarinc.com
Service Support Hotline 1-800-747-1522
© 2008 Raymar-Telenetics
Manufactured in the USA by RAYMAR-TELENETICS Manufactured in the USA by RAY
ITU-T V.22 (1200bps) ALL MODELS
ITU-T V.21 (0-300bps) “
ITU-T V.23 (1200/75bps) “
ITU-T V.34 (33.6Kbps to 19.2Kbps V.34M/33.6 only
V.32 TERBO (19.2Kpbs, 16.8Kbps) N/A V.32M/14.4
ITU-T V.32 BIS (14.4Kbps, 12.0Kbps) ALL MODELS
ITU-T V.33 (14.4Kbps, 12.0Kbps) “
ITU-T V.29 (9600, 7200, 4800bps) “
V.29FT (Fast Train) (9600, 7200, 4800bps) “
BELL 208 A/B (4800bps) “
ITU-T V.22 BIS (2400bps) “
BELL 212A (1200bps) “
BELL 103 (0-300bps) “
COMPATIBLE STANDARDS
ALTERNATE FALLBACK CAPABILITY
ITU-T V.17 (14.4k,12.0k,9600,7200bps) ALL MODELS
ITU-T V.29 (9600, 7200bps) “
ITU-T V.27TER (4800, 2400bps) “
ITU-T V.21 CHAN 2 T.30 (300bps) “
FAX MODE COMPATIBILITY
Class 1 ALL MODELS
Class 2 (TIA/EIA 578, preliminary EIA 2388) “
FAX OPERATION
FAX OPERATION
LEASED:
Tx Level: Selectable, 0 to -15dBm
ALL MODELS
CDThreshold: Selectable, -26, -33, -43dBm “
DIAL:
TX Level: Permissive or Selectable, 0 to -15dBm “
CD Threshold: Selectable, -26, -33, ir -43dBm
“
Dial Modes 33.6K to 300bps V.34/33.6 only
Leased Line Modes 33.6K to 2400bps V.34/33.6 only
Dial Modes 19.2K to 300bps NA v.32m/14.4
Leased Line Modes 19.2K to 2400bps NA v.32m/14.4
Dial Modes 14.4K to 300bps ALL MODELS
Leased Line Modes 14.4K to 3500bps ALL MODELS
DATA RATES
Full Duplex over 2-Wire Dial Lines ALL MODELS
Full Duplex over 2- or 4-Wire Leased Lines “
Half Duplex “
Simulated Half Duplex V.13 “
TELCO CONNECTION
RS232C/D, ITU-T V.24/28
Async: 230K to 300 bps
ALL MODELS
Sync: Internal, External, or Slaved Xmit Clock ALL MODELS
DTE (Data Terminal Equipment) CONNECTION
PHYSICAL CONNECTIONS
2- AND 4-Wire Leased Line (RJ45S and RJ11)
2-Wire Dial Line (RJ45S)
DIAG Port (RJ45S)
RS232C/D Port (DB25S)
Power (5-pin DIN Connector, 9/9VAC 50/60Hz)
12/24/48VDC Versions Available
Stand-Alone & Full-Height Rack Mount: 2.5”H x 9.7”W x 10.1”D
Half-Height Rack Mount Models: 1.25”H x 9.7”W x 10.1”D
PHYSICAL DIMENSIONS
Stand-Alone Model: 4 lb, 2 oz.
Full-Height Rackmount Model: 2 lb
Half-Height Rackmount Model: 1 lb, 8 oz
WEIGHT
WARRANTY
Raymar-Telenetics manufactured products are warranted
against defects in hardware material and workmanship under
normal use for one (1) year from date of original retail purchase.
Defective product will be repaired or replaced, determination to
be made by
Raymar-Telenetics , at no charge. Repaired or
replaced products are warranted for 90 days or for original
warranty period, whichever is longer. Warranty extends to
original end-user only.
0070-2702-000 REV:A
DHS: 09/16/2008
AUTOMATIC DIAL BACKUP
Penril modems support auto dial backup for leased line & dial applica-
tions. For leased line applications, the modem monitors the received
carrier level and signal quality; in the event performance drops below
selected thresholds, Penril modems will automatically establish a dial
connection to the remote modem. Automatic loopback allows the
communications path to be returned to the leased line when conditions
permit. In dial mode, the modem will redial the number stored in any
selected memory cell in the event the connection is lost.
AT & V.25bis AUTODIALERS
Automatic call origination is provided via an AT-compatible or ITU-T
V.25bis-compliant autodialer. The AT emulation mode allows the
modem to interface with a computer or device running intelligent
communications software designed to drive an AT-style modem. The
V.25bis autodialer complies with asynchronous and synchronous
international serial call origination standards.
V.54 DIAGNOSTICS
Versatile diagnostics are supported for rapid problem isolation and
uptime maximization. ITU-T V.54 tests plus selftest can be initiated from
the units front panel via AT commands throught the DTE interface or
through the DIAG port. Penril modems support Analog Loopback
(Loop3), Analog Loopback Selftest, Analog Loopback Selftest with
Errors, Remote Digital Loopback (Loop2), and Remote Digital Loopback
Selftest. In addition to diagnostic tests, Penril modems provide numer-
ous status displays for monitoring the DTE interface and telephone line
transmit and receive conditions. The status information is displayed on
the units front panel and is available remotely to minimize service calls
to remote locations.
V.42bis & MNP CLASS 5
The Penril modem family supports ITU-T V.42bis and MNP classes 1
through 5 to provide end-to-end error correction and data compression
between modems equipped with V.42bis or MNP in the asynchronous
operating mode. Error correction is provided by V.42 and MNP classes
2-4. Error correction and data compression is available in both dial and
leased line operation.
NETWORK SECURITY
Multiple levels of network security are provided by the Penril family of
modems. Penril modems can be programmed to provide manual
password protection (MPP) by calling back or passing through the
incoming caller after password validation. Automatic password protec-
tion (APP) can be used in the synchronous operating mode as well.
APP provides transparent security support by incorporating the
password as part of the modem training process. Additionally, the
Penril modem can be programmed to call back the originator during the
APP security process.
SOFT SETUP
Penril modems support multiple methods of modem configuration. The
LCD and six frontpanel pushbuttons can configure the unit and
alleviate the need for internal switches. AT commands can be used to
control configuration parameters through DTE interface. There is also
a separate DIAG port through which configuration can be done from a
dumb terminal or the Series 6000 Network Management System on
both the local and remote modems.
