BACK PANEL
DECODER VIDEO
EUROSCART FOR VCR/REC EUROSCART FOR TV
LNB PWR OUT
5,5 W MAX
CH
PAL I
PAL B/G
VIDEO
TSG
UHF OUT
ANT IN
30 WATTS
MAX
TechniSat ® VC 2002 S
* 1 Press this button if you wish to see a “Pay per View” programme.
4
STAND BY TechniSat VC 2002 S
APPLIANCE DESCRIPTION:
FRONT PANEL
AUTHORIZE BUTTON * 1
Digital Display STANDBY LED
Channel Up/Down Keys
AUDIO OUTPUTS L/R LNB IF IN
DECODER OUTPUT
VIDEO OUTPUT
SCART CONNECTION
FOR DECODER / VCR
SCART CONNECTION FOR TV TSG / VIDEO SWITC H ANT IN
UHF CHANNEL
ADJUSTMENT
(PRESET TO 36)
UHF OUT FUSE
MODULATOR SWITCH
PAL I / PAL G
Decoder Card Slot
