200911114 932954 • EN
Tripp Lite World Headquarters
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Warranty
1-YEAR LIMITED WARRANTY
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 1 year from the date of initial
purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, in its sole discretion. Service under this Warranty can
only be obtained by your delivering or shipping the product (with all shipping or delivery charges prepaid) to:
Tripp Lite; 1111 W. 35th Street; Chicago IL 60609; USA. Seller will pay return shipping charges. Visit www.tripplite.com/support before sending any equipment back for repair.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS
WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES,
INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY
EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you
may have other rights which vary from jurisdiction to jurisdiction).
Tripp Lite; 1111 W. 35th Street; Chicago IL 60609; USA
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to
great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any specific application.
The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
KVM Operation
Ports on the NetController KVM Switches can be accessed via Push-buttons, Hotkeys or OSD. In addition, the OSD allows you to perform various operations on the KVM switch.
To switch to a port via Push-button, simply press the Push-button of the port that you wish to access. To access ports via hotkey commands, or use the OSD to operate the KVM switch, see the table below:
1 Hotkeys in a hotkey command must be pressed within 2 seconds of each other for the command to be successful. 2 The Hotkey preceding sequence is user-definable, and can be changed to [Scroll Lock], [Caps Lock], [Num Lock] or [F12].
Hotkey Command Hotkey Sequence 1 OSD Procedure Description
Select port
(Single-stage
installation) [Scroll Lock] 2 ,
[Scroll Lock] 2 , ab
ab = 2-Digit Port
Number (01 – 16)
In the OSD Main Page, highlight the desired
port using the up and down arrow keys
(
[Page Up] and [Page Down] displays
additional ports) and press the [Enter] key.
Switches console focus to the selected port.
Select port
(Daisy-chain
installation) [Scroll Lock] 2 , [Scroll
Lock] 2 ab, yz
ab = 2-Digit Station
Number (01 – 16)
yz = 2-Digit Port
Number (01 – 16)
In the OSD Main page, highlight the desired
port using the up and down arrow keys
(
[Page Up] and [Page Down] displays
additional ports and KVMs) and press the
[Enter] key.
Switches console focus to the selected KVM
switch and port.
Next Lower Port [Scroll Lock] 2 ,
[Scroll Lock] 2 , [ ↓]
— Switches console focus from the current port
to the next accessible port prior to it.
Next Higher Port [Scroll Lock] 2 ,
[Scroll Lock] 2 , [ ↑]
— Switches console focus from the current port
to the next accessible port after it.
Next Lower
Station [Scroll Lock] 2 ,
[Scroll Lock] 2 ,
[Page Up]
— Switches console focus from the current port
to the first accessible port on the next lower-
level KVM switch.
Next Higher
Station [Scroll Lock] 2 ,
[Scroll Lock] 2 ,
[Page Down]
— Switches console focus from the current
port to the last accessible port on the next
higher-level KVM switch.
Beep On/Off [Scroll Lock] 2 ,
[Scroll Lock] 2 , [B]
— Toggles the Beeper On/Off. The Beeper
sounds when performing a Hotkey
Command or during an Auto Scan.
Initiate an Auto
Scan [Scroll Lock] 2 ,
[Scroll Lock] 2 , [S]
Press the [F2] key when in any of the OSD
Pages.
Initiates an Auto Scan. Press any key to stop
an Auto Scan.
Title Bar On/Off [Scroll Lock] 2 ,
[Scroll Lock] 2 , [T]
— Turns the Title Bar On/Off. Note: This does
not affect the Title Bar setting in the OSD.
Reset Console
Mouse [Scroll Lock] 2 ,
[Scroll Lock] 2 , [End]
— Resets the console mouse in the event of
a lockup.
Open the OSD
Menu [Scroll Lock] 2 ,
[Scroll Lock] 2 ,
[Spacebar]
— Opens the OSD Menu.
Change the
Hotkey Preceding
Sequence [Scroll Lock] 2 ,
[Scroll Lock] 2 , [H], y
y = [Scroll Lock],
[Caps Lock],
[Num Lock] or [F12]
In the OSD Setup Page, highlight the Hotkey
setting and use the [
→] and [←] keys to se-
lect the desired Hotkey preceding sequence.
Press the
[Enter] key to save the change.
Changes the hotkey preceding sequence to
[Scroll Lock], [Caps Lock], [Num Lock]
or
[F12]
Last Known
Active Port
Restore [Scroll Lock] 2 ,
[Scroll Lock] 2 , [L]
— Enables/Disables the feature that restores
the KVM switch to the last port to have the
KVMs focus prior to a power failure.
Hotkey Command Hotkey Sequence 1 OSD Procedure Description
Load Default — In the OSD Setup Page, highlight the Load
Default setting and press the
[Enter] key.
When prompted to confirm the action,
highlight Yes and press the
[Enter] key.
Restores the OSD Settings to the factory
defaults. Note: This does not affect password
security.
OSD Appearance — In the OSD Setup Page, highlight the OSD
Appearance setting and use the
[ →] and [←]
keys to select Yes or No. Yes turns on the
OSD Appearance function; No turns it Off.
When this setting is turned on, the OSD will
remain open instead of closing when the
OSD Main Page is used to switch ports.
Edit Port Names — In the OSD Main Page, highlight the desired
port and press the
[Insert] key. Type in a
port name and press the [Enter] key. Port
names can be up to 16 characters, using
A – Z, 0 – 9.
Edits the name assigned to a port.
Auto Scan Period — In the OSD Setup Page, highlight the Auto
Scan Period setting and use the
[ →] and
[ ←] keys to choose a time frame between
5 and 95, with intervals of 5 seconds. Press
the
[Enter] key to save the setting.
Sets the amount of time spent on each
computer during an Auto Scan. The default
is 10 seconds.
Auto Logout — In the OSD Setup Page, highlight the Auto
Logout setting and use the
[ →] and [←]
keys to choose a time frame between 00
and 99 seconds. A setting of 00 disables
this feature. Press the
[Enter] key to save
the setting.
Sets the amount of inactivity time before a
user is logged out of the KVM switch,
requiring a password to regain access. The
default is 00, which disables this feature.
OSD Timeout — In the OSD Setup Page, highlight the OSD
Timeout setting and use the
[ →] and [←]
keys to choose a time frame between 00 and
95 seconds, with intervals of 5 seconds. A
setting of 00 disables this feature. Press the
[Enter] key to save the setting.
Sets the amount of inactivity time before the
OSD is closed. The default is 30 seconds.
Title Bar Position — In the OSD Setup Page, highlight the Title
Bar setting and use the
[ →] and [←] keys
to choose between 5 options: Disable, Left,
Right, Left Timed, Right Timed. Press the
[Enter] key to save the setting.
Determines if the Title Bar is displayed when
switching ports; and, if so, what side of the
screen it is on and how long it is displayed
for. The timed settings turn the title bar off
after 5 seconds.
Password — In the OSD Setup Page, highlight the
Password setting and press the
[Enter] key.
Choose Yes to enable password security
or No to disable it, and then hit the
[Enter]
key. If enabling password security, you
will be asked to enter in a new password.
Passwords can be up to 8 characters (A – Z,
0 – 9). If disabling password security, you will
be asked to enter in the previous password.
Enables/Disables password security. When
enabled, a user is required to enter a
password to regain access to the KVM
switch after they have been logged out.
