Page 4
4
5. NOMENCLATURE AND DIMENSIONS
The illustrations assume that the front grille is mounted to the speaker.
295
129
318
90 *
1
83.5 *
2
162
[Front]
[Bottom]
[Side]
[Rear]
(Unit: mm)
Front grille
Connector for impedance selection
Detachable input connector
Speaker
Lock tab
46 *
2
5.6 (5.5)
1.6 (1.5)
203
ø21.6
120 *
1
Dimensions in parentheses ( ) apply to the H-3WP.
*
1
For mounting to a wall
*
2
For mounting to two-gang electrical box
• Base Frame (Accessory)
