Hints for test centres
Before starting any test it is necessary to fill completely with salt the salt container and with rinse aid the rinse
aid dispenser.
IST10en
Test standard
EN 50242
Reference programme:
BIO WASH 50°
Load:
12 standard place settings
Rinse aid selector:
position 5
Detergent dosage :
25 g in the dispenser
5 g on the dispenser lid
UI49
US57
Arrangement
upper basket
Arrangement
lower basket
Arrangement
cutlery basket
DIMENSIONS
Width
60 cm
Height with worktop
85 cm
Height without worktop
82 cm
Max depth
61 cm
Max depth with open door
115.2 cm
ELECTRICAL CONNECTION
Voltage
230 V - 50 Hz
MOTOR RATING DURING WASH
200 W
POWER OF HEATING ELEMENT
2100 W
OVERALL POWER
2300 W
WATER SUPPLY PRESSURE
Minimum
50 kPa (0.5 bar)
Maximum
800 kPa (8 bar)
CAPACITY
12 place settings
Technical specifications
