Quantum SPEED QUEEN SFNLCFS - Manual (Page 4)

© 2012 alliance Laundry Systems LLC aM10-0780r2
www.speedqueen.com
Washers Single Load Dryers Stack Dryers Stack Washer/Dryers
SFNLCFS, SFNLCFJ,
SFNLYFS, SFNLYFJ
Electric:
Gas:
SDELCFG, SDELYFG
SDGLCFG, SDGLYFG
Electric:
Gas:
:
SSELCFGS, SSELCFGW
SSELYFGS, SSELYFGS
SSGLCFGS, SSGLCFGW
SSGLYFGS, SSGLYFGW
Electric:
Gas:
STELCFS, STELYFS
STGLCFS, STGLYFS
Basket/Cylinder Volume - cu.ft. (liters) 2.84 (80) 7.0 (198) 7.0 (198) 2.84 (80)/7.0 (198)
Width - in (mm) 26 7/8" (683)
26 7/8"
(683)
26 7/8" (683) 26 7/8" (683)
Depth - in (mm) 28" (711) 28" (711) 28" (711) 28" (711)
Height* - in (mm) 43" (1092) 43" (1092) 76 5/8" (1946) 76 5/8" (1946)
Weight - lb (kg) 250 (113)
Electric:
Gas:
150 (68)
155 (70)
Electric:
Gas:
265 (120)
275 (125)
Electric:
Gas:
360 (163)
365 (166)
Shipping Weight - lb (kg) 270 (123)
Electric:
Gas::
160 (73)
165 (75)
Electric:
Gas:
280 (127)
290 (132)
Electric:
Gas:
390 (177)
395 (179)
Cycle Time - minutes (default) 27 45 45 27/45
Motor HP (Capacitor Start and Thermal
Protected)
1 HP, 750W 1/3 HP, 5.5 amps 1/3 HP, 5.5 amps
1 HP, 750W
1/3 HP, 5.5 amps
Water Consumption - gal (Liter) 11.0 (41.7) N/A N/A 11.0 (41.7)
Water Factor - gal/ft³ (Liters/Liter/cycle) 4.0 (0.53) N/A N/A 4.0 (0.53)
Modified Energy Factor - ft³/kWh/cycle
(Liters/kWh/cycle)
2.40 (67.97) N/A N/A 2.40 (67.97)
Average Hot Water Usage - gal (Liter) 0.9 (3.3) N/A N/A 0.9 (3.3)
Water Pressure - psi (bar)
Pressure fill
20 to 120 (1.4/8.3)
N/A N/A
Pressure fill
20 to 120 (1.4/8.3)
Spin Speed - RPM 500, 650, 1000 N/A N/A 500, 650, 1000
Cycle/Temperature
Hot Normal
Warm Perm Press
Cold Delicate
High
Medium
Low
Delicate
No Heat
160 º
155 º
145 º
115 º
High
Medium
Low
Delicate
No Heat
160 º
155 º
145 º
115 º
See washer and dryer
columns for corresponding
cycles and temperatures.
Electrical Specifications and Circuit
Requirements
120/60/1-15 amp
Electric:
Gas:
120/240/60/1-30 amp
120/208/60/1-30 amp
120-60/1-15 amp
Electric:
2 ea
Gas:
2 ea
120/240/60/1-30 amp
120/208/60/1-30 amp
120-60/1-15 amp
See washer and dryer
columns for corresponding
cycles and temperatures.
Btu per Hour (kcal) N/A 25,000 (6300) 25,000 (6300) 25,000 (6300)
Heating Element**
N/A 5350W, 240V
4750W, 208V
5350W, 240V
4750W, 208V
5350W, 240V
4750W, 208V
Type of Gas (Gas models only)
N/A Factory-equipped natural/mixed gas
convertible to LP gas***
Factory-equipped natural/mixed
gas convertible to LP gas***
Factory-equipped natural/mixed
gas convertible to LP gas***
Utility Connections - in (mm) N/A Gas: 3/8" NPT (9.5) Gas: 3/8” NPT (9.5) Gas: 3/8" NPT (9.5)
Air Outlet Diameter - in (mm) N/A 4" (102) 4" (102) 4" (102)
Exhaust Airflow† - cfm (liters/sec) N/A 220 (105) 220 (105) 220 (105)
Maximum Exhaust Static Back Pressure N/A 0.6" W.C. 0.6" W.C. 0.6" W.C.
Agency Approval
cULus Electric:
Gas:
cULus
CSA Star
Electric:
Gas:
cULus
CSA Star
Electric:
Gas:
cULus
CSA Star
Activation Coin/Card Op Coin/Card Op Coin/Card Op Coin/Card Op
Top and Lid Finish Porcelain Porcelain N/A N/A
Colors White White White White
Door Type Window Solid Solid, Window Window
QUANTUM™ SYSTEM COMMERCIAL WASHER & DRYER SPECIFICATIONS
* Heights may vary slightly depending on leveling adjustments.
** electric dryers come equipped for 120/240/60/1 operation. They can be field converted to operate on 120/208/60/1 with optional 61928 conversion kit.
Gas dryers can be field converted for operation on LP gas with optional 458P3 conversion kit.
*** iMPorTanT: any product revisions or conversions must be made by the Manufacturer’s authorized Dealers, Distributors, or local service personnel.
† Measured at point of exit from dryer.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements, design and specifications subject to change
without notice. The quality management system of alliance Laundry Systems’ ripon facility has been registered to iSo 9001:2008.
