Cooling Requirements
The amplifier has a rear-mounted variable-speed
fan. Speed is determined by the temperature of
the amplifier’s internal heat sink assembly.
Cooling air enters the rear of the amplifier and
exhausts from the front vents.
If mounting in an enclosure, be certain not to
restrict airflow.
Do not obstruct cooling air vents!
Cooling Air Inlet and Exhaust Vents
Warm air
exhausts
through
the front
panel
vents.
Equipment Rack
Cool air is
pulled into the
rear of the
amplifier.
Amplifier
Fan
