Page 4

SC20

SC30

SC40

SC60

SC80

Control Option

Gold, Silver, Standard

Capacity - lb (kg)

20 (9)

30 (13.6)

40 (18)

60 (27)

80 (36)

Overall Width - in (mm)

26" (660)

29" (737)

30 5/8" (778)

34 1/16" (865)

41 1/2" (1054)

*Overall Depth - in (mm)

30 1/4" (767)

34 9/16" (878)

39 3/4" (1009)

42 9/16" (1081)

51 1/2" (1308)

Overall Height - in (mm)

42" (1067)

45" (1142)

47 1/4" (1199)

49 7/8" (1267)

56 3/16" (1426)

Cylinder Diameter - in (mm)

21" (533)

24" (610)

26 1/4" (667)

30" (762)

36" (916)

Cylinder Depth - in (mm)

13 3/4" (349)

16" (406)

20 1/4" (514)

22" (559)

Cylinder Volume - cu. ft. (liters)

2.76 (78.1)

4.19 (118)

6.34 (180)

9.0 (255)

12.4 (354)

Door Opening Size - in (mm)

11 5/8" (295)

14 5/16" (364)

16 1/4" (413)

18 1/2" (470)

Door Bottom to Floor - in (mm)

14 3/8" (365)

14" (356)

14 1/2" (368)

14 15/16" (379)

17 15/16" (455)

Water Inlet Connection - in (mm)

2 @ 3/4" (19)

Drain Diameter - in (mm)

1 @ 2" (52)

1 @ 3" (76)

Drain Height to Floor - in (mm)

4 1/2" (114)

4 13/16" (122)

4 11/16" (119)

5 3/4" (145)

2 Speed

F/V Speed

2 Speed

F/V Speed

2 Speed

F/V Speed

2 Speed

F/V Speed

Wash

.15 (.11)

N/A

.24 (.18)

N/A

.40 (.30)

N/A

.55 (.41)

N/A

High Extract

.74 (.55)

1 (.75)

1.34 (1.0)

1 (.75)

1.8 (1.3)

2 (1.7)

2.7 (2.01)

3 (2.2)

5 (3.7)

Total # of Speeds

6, 8

Gentle

N/A

29 (.25)

N/A

27 (.25)

N/A

26 (.25)

N/A

24 (.25)

22 (.25)

Wash

55 (.9)

52 (.8)

49 (.8)

48 (.8)

51 (1)

46 (.8)

47 (.9)

43 (.8)

40 (.8)

Distribution

N/A

92 (2.5)

N/A

86 (2.5)

N/A

82 (2.5)

N/A

77 (2.5)

70 (2.5)

Very Low

N/A

366 (40)

N/A

343 (40)

N/A

328 (40)

N/A

307 (40)

280 (40)

Low

519 (80)

518 (80)

468 (75)

485 (80)

486 (88)

464 (80)

450 (86)

434 (80)

396 (80)

Medium

N/A

580 (100)

N/A

542 (100)

N/A

518 (100)

N/A

485 (100)

443 (100)

** High

N/A

635 (120)

N/A

594 (120)

N/A

568 (120)

N/A

531 (120)

485 (120)

**Very High

N/A

686 (140)

N/A

641 (140)

N/A

613 (140)

N/A

574 (140)

524 (140)

B 120/60/1

20-16

N/A

F 440-480/60/3/3

15-4 N/A

15-5 N/A

N/A

C 380-415/50/4/3

15-4 N/A

15-5 N/A

N/A

J 200/50/3/3

15-5

N/A

15-7

N/A

20-7

N/A

20-10

N/A

208/220 - 240/60/2/3/1

15-8 N/A

20-10

N/A

30-14

N/A

N/A N/A

N/A

O 208/220-240/60/3/3

15-3

N/A

15-7

N/A

20-7

N/A

20-10

N/A

200-208/220-240/50/60/3/3

N/A 15-5

N/A 15-6

N/A 15-8

15-11

380-415/440-480/50/60/3/3

N/A 15-4

N/A 15-4 N/A 15-5

N/A 15-6

15-8

200-208/220-240/50/60/3/1/3

N/A 15-6

N/A 15-7

N/A 15-10

N/A 15-11

20-16

Width

29 1/2" (749)

32 1/2" (828)

34 1/4" (867)

38" (965)

48" (1219)

Depth

34 5/8" (879)

39 13/16" (1014)

44 5/8" (1133)

49" (1245)

56" (1422)

Height

51 1/2" (1308)

54 1/2" (1389)

56 3/4" (1441)

59 3/8" (1508)

65 3/4" (1670)

Net Weight - lb (kg)

387 (176)

489 (222)

692 (314)

812 (368)

1374 (623)

Shipping Weight - lb (kg)

420 (191)

530 (240)

734 (333)

854 (387)

1461 (663)

Export Shipping Weight - lb (kg)

475 (215)

593 (269)

816 (370)

948 (430)

1573 (714)

****Agency Approvals

cETLus, CE

www.speedqueen.com

AC09-210

Vended Quantum

™

Washer-Extractor Specifications

*Overall depth includes vacuum breaker to door handle.

**High & Very High Spin Speeds are available on the V Speed models only.

***Circuit breaker and amp draw data shown are for models without electric heat. Consult factory for other configurations. Manufacturer strongly recommends using a

circuit breaker instead of fuses. Use 3-pole circuit breakers for 3-phase machines.

**** Agency approvals may vary depending on configuration. Consult factory for details. Steam connection requires 1/2" N.P.P.

For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements, design and
specifications subject to change without notice. The quality management system of Alliance Laundry Systems’ Ripon facility has been registered to ISO 9001:2000.

*** Voltage/Hz
# of wires/
Phase/
Circuit Breaker
- FLA

Motor Power Consumption -
HP (kW)

Cylinder Speeds -
RPM (G-Force)

Shipping Dimensions
Approx. - in (mm)
