Input / Output Control and Monitoring
■ Input sensitivity selection: 1V or 3V
■ Input source select: Normal/Page
■ Level control
■ Pre-/Post-fader audio signal monitoring
■ Mute control
■ Signal polarity control
■ Pre-/Post-fader signal level metering
Amplifier Output Monitoring
■ Output voltage and current metering
■ Output power in watts
■ Output clip detection monitoring
■ Headroom metering
■ Output signal (speaker terminal) audio monitoring
Load Monitoring
■ Open/shorted load detection
■ Adjustable threshold for detecting load opens and shorts
■ Continuously updated average impedance measurement
Amplifier Management
■ AC standby/operate mode selection
■ AC mode indication (Off/Standby/On)
■ Protect status monitoring
■ Operating temperature metering
■ Overtemp indicator with adjustable overtemp threshold
■ Gain control monitoring
■ Model ID indication
■ Bridge Mono/Parallel/Stereo mode indication
Other Features
■ Fifteen user-definable configuration presets
■ RS-232 port for diagnostics and preset control
■ Internal sine wave signal generator available for system diagnostics
(accessible via Telenet only)
■ Page input with selectable 1V or 3V sensitivity
■ One contact closure input
■ One floating dry-contact SPDT (Single Pole Double Throw) relay output
■ Audio monitor bus with selectable tap points, mixing, and balanced I/O
■ Recessed front panel bypass switch
■ Firmware is updateable via the network to add future upgrades
QSControl Amplifier Network Monitor
The CM16a Amplifier Network Monitor is a key hardware component of QSControl, QSC’s
Ethernet-based audio network. Each CM16a provides sixteen channels of audio level control,
monitoring, and amplifier management for DataPort-equipped QSC amplifiers. The CM16a is
operated remotely by a Windows-based PC functioning as the System Controller running
QSControl application software. Control and monitor data is communicated between the System
Controller and CM16a over an Ethernet network. The CM16a, located in the amplifier rack, is linked
to amplifiers via DataPort cables. The CM16a also serves as the network interface for QSC’s digital
signal processors, including the DSP-3.
CM16a
Mandalay Bay Resort, Las Vegas
Petronas Towers, Malaysia
Heinz Field, Pittsburgh
Miller Park, Milwaukee
The Galaxy Theater, California
