Installation & Programming Manual
FX & VFX “E” Series Inverter/Charger System
Copyright 2003
OutBack Power Systems, Inc.
900-0027-2
19009 62
nd
Ave NE, Arlington WA 98223 USA
Page 1
Rev 7.1
06/08/06 Tel 360 435 6030 Fax 360 435 6019
OutBack Power Systems
“Export” FX and VFX Inverter/Charger
I n s t a l l a t i o n a n d P r o g r a m m i n g M a n u a l
Document Revision 7.1
FX 2012ET - 2.0 kW / 12 VDC / 230 VAC / 50 Hz (Sealed + Turbo / Export)
FX 2024ET - 2.0 kW / 24 VDC / 230 VAC / 50 Hz (Sealed + Turbo / Export)
FX 2348ET - 2.3 kW / 48 VDC / 230 VAC / 50 Hz (Sealed + Turbo / Export)
VFX 2612E - 2.6 kW / 12 VDC / 230 VAC / 50 Hz (Ventilated / Export)
VFX 3024E - 3.0 kW / 24 VDC / 230 VAC / 50 Hz (Ventilated / Export)
VFX 3048E - 3.0 kW / 48 VDC / 230 VAC / 50 Hz (Ventilated / Export)
The “Sealed” version of the FX The “Vented” version of the FX
The “Turbo Kit” that comes with the FX “ET” series is shown on page 17
Please check our website at
www.outbackpower.com
for the latest product information
