10
Oricom PMR755 2-Way CB Radio
Antenna
Speaker
MIC (microphone)
LCD Screen
- Displays the current
Channel selection and
Other radio symbols.
PTT (push to talk) button
- press and hold To transmit.
(UP)/(DOWN)buttons
- press to change
channels, volume, and
to select settings during
programming.
(Power)button
- press and hold to Turn the
PMR Unit ON or OFF.
MENU button
- press to program The PMR
settings.
CALL button
- press to send a ringing
Tone to other PMR units.
LCD Screen
Channel Number. Changes from 1 to 40 as
selected by the user.
Displays when battery level goes low.
Displayed in channel selection mode.
Displayed in volume selection mode.
Displayed when transmitting a signal.
Displayed when receiving a signal.
