Page 4: Daves elevates your audio/video experience

How

Works

Satellite

Cable Box

DVD

VCR

(etc,)

SOURCE ROOM

Cat-5 Wire

(1 per room)

Supports up to

1000 ft length

Up to 4

Input Sources

Daves - Matrix Switcher

(DAV-1-MATRIX)

VIEWING/LISTENING ROOM 1

In-ceiling

Speaker

In-wall

Speaker

In-wall Receiver

In-wall Keypad Amplifier

VIEWING/LISTENING ROOM 3

VIEWING/LISTENING ROOM 4

VIEWING/LISTENING ROOM 2

DAVES keeps all of your equipment in one area and distributes the Audio/Video signal throughout the house over a single Cat-5 wire per room.
All video, digital audio, and infrared signals transmit from the Matrix Switcher through the Cat-5 wire simultaneously. The signal then goes to the
in-wall receiver and to the television for video. It then travels from the in-wall receiver to the in-wall keypad/amplifier and then out to the speakers.
Either the keypad or your remote control will allow you to select the equipment and audio/video - instantly.

Plasma TV

DAVES Elevates Your Audio/Video Experience!
