Page 4

LED FLASHING MODES

OM-EL-USB-LITE features a bi-color LED to indicate the status of the data logger. To save power, the status indication only operates
when the push button is pressed for a short while.

BATTERY REPLACEMENT

We recommend that you replace the battery every 1 month, or prior to logging critical data. The OM-EL-USB-LITE does not lose its stored
readings when the battery is discharged or when the battery is replaced; however, the data logging process will be stopped and cannot
be re-started until the battery has been replaced and the logged data has been downloaded to a PC.

For maximum logging life, only use Maxell or Panasonic CR1620 lithium batteries. Before replacing the battery, remove the
OM-EL-USB-LITE from the PC.

Note:
Leaving the OM-EL-USB-LITE plugged into the USB port for longer than necessarywill cause some of the battery capacity to be lost.

WARNING

Handle lithium batteries carefully. Dispose of in accordance with local regulations.

OM-EL-USB-LITE

Low Cost USB Temperature Data Logger

DIMENSIONS

All dimensions in mm (inches)

68.0 (2.67)

8.5 (0.72)

Red/Green LED

Green single fl ash
The data logger is currently logging. No alarm on the channel.

Red single fl ash
The data logger is currently logging. Low alarm on the channel.

Red double fl ash
The data logger is currently logging. High alarm on the channel.

Specifi cations liable to change without prior warning
