European Specifications
Sealed Models Vented Models
FX2012ET FX2024ET FX2348ET VFX2612E VFX3024E VFX3048E
Nominal DC Input Voltage 12 VDC 24 VDC 48 VDC 12 VDC 24 VDC 48 VDC
Continuous Power Rating at 25° C 2000 VA 2000 VA 2300 VA 2600 VA 3000 VA 3000 VA
AC Voltage/Frequency 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz
Continuous AC RMS Output at 25° C 8.7 amps AC 8.7 amps AC 10.0 amps AC 11.3 amps AC 13.0 amps AC 13.0 amps AC
Idle Power Full ~ 20 Watts ~ 20 Watts ~ 23 Watts ~ 20 Watts ~ 20 Watts ~ 23 Watts
Search ~ 6 Watts ~ 6 Watts ~ 6 Watts ~ 6 Watts ~ 6 Watts ~ 6 Watts
Typical Efficiency 90% 92% 93% 90% 92% 93%
Total Harmonic Distortion Typical 2% 2% 2% 2% 2% 2%
Maximum 5% 5% 5% 5% 5% 5%
Output Voltage Regulation ± 2% ± 2% ± 2% ± 2% ± 2% ± 2%
Maximum Output Current Peak 28 amps AC 35 amps AC 35 amps AC 28 amps AC 35 amps AC 35 amps AC
RMS 20 amps AC 25 amps AC 25 amps AC 20 amps AC 25 amps AC 25 amps AC
AC Overload Capability Surge 4600 VA 5750 VA 5750 VA 4600 VA 5750 VA 5750 VA
5 Second 4000 VA 4800 VA 4800 VA 4000 VA 4800 VA 4800 VA
30 Minutes 2500 VA 3100 VA 3100 VA 3100 VA 3300 VA 3300 VA
AC Input Current Maximum 30 amps AC 30 amps AC 30 amps AC 30 amps AC 30 amps AC 30 amps AC
AC Input Voltage Range (MATE Adjustable) 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC
AC Input Frequency Range 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz
DC Input Voltage Range 10.5 to 17.0 VDC 21.0 to 34.0 VDC 42.0 to 68.0 VDC 10.5 to 17.0 VDC 21.0 to 34.0 VDC 42.0 to 68.0 VDC
Continuous Battery Charge Output 100 amps DC 55 amps DC 35 amps DC 120 amps DC 85 amps DC 45 amps DC
Warranty Standard 2 year / Optional 5 year Standard 2 year / Optional 5 year
Weight Unit 62.2 lbs (28.4 kg) 61 lbs (27.7 kg)
Shipping 67 lbs (30 kg) 64 lbs (29 kg)
Dimensions (H x W x L) Unit 13 x 8.25 x 16.25” (33 x 21 x 41 cm) 12 x 8.25 x 16.25” (30 x 21 x 41 cm)
Shipping 21.75 x 13 x 22” (55 x 33 x 56 cm) 21.75 x 13 x 22" (55 x 33 x 56 cm)
