Step 30. Select the Deviation Control Type Submenu
Press
d . If flashing _DEV Deviation is displayed press a ,
otherwise press b until flashing _DEV is shown. Now
press d to store and go to next menu item.
Step 31. Select the Latched Type Submenu
Press
d . If flashing UNLT Unlatched is displayed press a ,
otherwise press b until UNLT is displayed.
Press d to store and advance to next menu item.
Step 32. Select the Normally Open Type of Contact
Closure Submenu
Press
d . If flashing N.o. Normally Open is displayed,
press a , otherwise press b until N.o. is displayed. Press d
to store and advance to next menu item.
Step 33. Select the Above Type of Active Submenu
Press
d . If flashing ABoV Above is displayed, press a ,
otherwise press b until ABoV is displayed. Press d to store
and advance to next menu item.
Step 34. Enable Alarm 1 at Power On ( A.P.oN)
Press d . If flashing ENBL is displayed, press a , otherwise
press b until ENBL is displayed. Press d to store and
advance to next menu item.
Step 35. Enter Alarm 1 High Submenu
Press
a twice to skip ALR.L Alarm 1 Low value. ALR.L is
for below & ALR.H for above.
Step 36. Set the Alarm 1 High value ( ALR.H)
Press d . Press b or c until value to set the display to
002.0. Press d to save.
Step 37. Enter the Alarm 2 Menu
The display will show
ALR2 the top menu for Alarm 2.
Repeat steps from 28 to 36 to set for Alarm 2 the same
conditions as for Alarm 1.
Step 38. Configuration of Display Color Selection
Press
a until the COLR Display Color Selection Menu
appears on the Display. Configure COLR as N.CLR / GRN
(green), 1.CLR / RED (red), 2.CLR / AMBR (amber). Please
refer to the operator’s manual if needed.
Step 39. Run a Test
Press
a until reset the controller and return to RUN Mode
to display 075.0 (Ambient Temperature). Now you are
ready to observe temperature as it rises 10°F higher than
displayed. Touch the tip of the Thermocouple to raise the
temperature above the Alarm 2 High value
082.0, and AL2
will turn on, and Display Color will change from Green to
Amber. Continue touching the tip to raise the temperature
above the Alarm 1 High value
087.0 and Display Color will
change from Amber to Red.
Step 11. Enter to the Thermocouple Type Input Submenu
Press
d to display flashing, previously selected Thermocouple
type.
Step 12. Scroll through available selection of TC types
Press
b to sequence thru flashing Thermocouple types,
(select k -for type "K" CHROMEGA ® /ALOMEGA ® )
J K T E N DIN J R S B C - TC types
J k t E N dN J
R S b C - Display
Step 13. Store TC type
After you have selected the Thermocouple type press
d to
store your selection, the instrument automatically advances
to the next menu item.
Step 14. Enter to Reading Configuration Menu
The display shows
RDG Reading Configuration, which is the
top menu for 4 submenus: Decimal Point, Degree Units,
Filter Constant and Input/Reading Submenus.
Step 15. Enter to Decimal Point Submenu
Press
d to show DEC Decimal Point.
Step 16. Display the Decimal Point position
Press
d again to display the flashing Decimal Point position.
Step 17. Select the Decimal Point position
Press
b to select FFF.F Decimal Point position.
Step 18. Store selected Decimal Point position
By pressing
d momentarily the Decimal Point position will
be stored and the instrument will go to the next menu item.
Step 19. Enter to Temperature Unit Submenu
Display shows
TEMP Temperature Unit.
Step 20. Display available Temperature Units
Press
d to display the flashing Degree °F or °C.
Step 21. Scroll through Temperature Units selection
Press
b to select °F Degree.
Step 22. Store the Temperature Unit
Press
d to display momentarily that the Degree Unit has
been stored and the instrument will go automatically to the
next menu item.
Step 23. Enter the Filter Constant Submenu
Display shows
FLTR Filter Constant Submenu.
Step 24. Display the Filter Constant Value Submenu
Press
d to display the flashing, previously selected Filter
Constant.
Step 25. Scroll through available Filter Constants
Press
b to sequence thru Filter Constants 0001, 0002,
0004, 0008, 0016, 0032, 0064 and 0128.
Step 26. Store the Filter Constant
Press
d momentarily to store 0004 Filter Constant and the
instrument will automatically go to the next menu item.
Step 27. Enter Alarm 1 Menu
The display will show
ALR1 the top menu for Alarm 1. In the
following steps we are going to enable Alarm 1, Deviation,
Unlatch, Normally Open, Active Above, Enable at power on
and +2°F High Alarm i.e. Process Value > Setpoint 1 Value
+2°F will activate Alarm 1.
Step 28. Enter Alarm 1 Enable/Disable Submenu
Press
d to display flashing DSBL / ENBL.
Step 29. Enable Alarm 1 Submenu
If flashing
ENBL is displayed, press a , if DSBL is displayed,
press b until ENBL is displayed, then press d to store and
go to the next menu item.
