Maintenance general information – Oreck Vaccum Cleaner David User Manual

Page 6

WARNING: Unplug cord from electrical outlet before servicing.

Remove the replacement belt from the storage channel.
Remove the door by removing the hold down screw located on side of power head.
Fold door away from the power head and lift it away.
Remove the belt from the motor drive shaft and brush roll pulley.
Loop the new belt over the brush roll pulley. Place the opposite end of the belt on the motor drive shaft.
Replace the door by placing the bottom tab on door into slots located inside power head and pressing the
door closed.
Replace the hold down screw and tighten.

Replacing Worn Belt

Maintenance

General

Information

Lubrication

The vacuum cleaner motor bearings are factory lubricated and sealed. Further lubrication is not required.

CAUTION

Wood Floors, Soft (Vinyl, Asphalt Tile, etc.) Floor Surfaces and Polished Floor Finishes

Use floor and floor finish manufacturer’s recommended methods of cleaning. The
roller brush may also scuff very soft finishes. Do not operate the unit while in the
upright and locked position. Do not let the unit run while in any one stationary posi-
tion for any period of time. Keep the unit moving while in operation.
Note: At least once a month, check for and remove excessive lint, string or hair from
revolving brush. Patented cleaning grooves on brush roll will allow easier cleaning.
Wipe the outside of the cleaner with a damp cloth. Also clean the connector deflector
assembly area, base of cleaner and fan housing area. If there is dust in the outer bag,
vacuum it or shake it out.
A little preventative maintenance will keep your cleaner looking new and will ensure
continued cleaning effectiveness.
