SETUP
– 8 –
EN
Analog Audio Connection
Digital Audio Connection
AUDIO OUT
DIGITAL AUDIO OUT
SETUP > QUICK >
DOLBY DIGITAL
Connecting to a Dolby Digital decoder
for Dolby Digital audio output.
BITSTREAM
Connecting to other device (an MD deck
or DAT deck etc.) without Dolby Digital
decoder.
PCM
Connection to an Audio System
* To complete these settings, refer to pages 19-21.
Note:
• The audio source on a disc in a Dolby Digital multi channel
surround format cannot be recorded as digital sound by an MD
or DAT deck.
• By hooking this unit up to a Dolby Digital decoder, you can
enjoy high-quality Dolby Digital multi channel surround sound
as heard in the movie theaters.
• Playing back a DVD using incorrect settings may generate
noise distortion and may also damage the speakers.
Audio
This unit
Connection
Setting
Supplied cables used in this connection are as
follows:
• RCA audio cable (L/R) x 1
Please purchase the rest of the necessary cables at
your local store.
L
R
VIDEO
OUT
Y
C
B
/P
B
AUDIO
OUT
R
L
AUDIO
OUT
VIDEO
OUT
COAXIAL
R
L
Y
COMPONENT VIDEO OUT
CR/PR
DIGITAL
AUDIO OUT
CB/PB
HDMI OUT
AUDIO
OUT
VIDEO
OUT
COAXIAL
R
L
Y
COMPONENT VIDEO OUT
C
R
/P
R
DIGITAL
AUDIO OUT
C
B
/P
B
HDMI OUT
COAXIAL
analog audio
input jacks
RCA audio cable
digital audio
input jack
digital audio coaxial cable
stereo system
Dolby Digital decoder,
MD deck or DAT deck
