System Options
Internet Fax Function Specifications
Scanning Function Specifications (Standard) bizhub C550 Specifications
Protocol SMTP, POP
Connection Mode Full-Mode
Sending Paper Size Max. A3 (Long Length Support: Max. 1,000mm)
Recording Paper Size Max. A3
Interface Ethernet 10BASE-T/100BASE-TX/1000BASE-T
Resolution 200 ✕ 100dpi, 200 ✕ 200dpi , 400 ✕ 400dpi, 600 ✕ 600dpi
Data Format TIFF, JPEG, PDF, Compact PDF
Fax Function Specifications (Optional)
Send Size Max. A3 (Long Length Max.1,000mm)
Record Size Max. A3 (Long Length Record Max.1,000mm - following the page division)
Communication Standard Super G3
Line Density G3: 8 ✕ 3.85, 8 ✕ 7.7, 8 ✕ 15.4, 16 ✕ 15.4 line/mm,
200 ✕ 200dpi, 400 ✕ 400dpi, 600 ✕ 600dpi
Communication Time Less than 3 sec. (V.34, JBIG)
Communication Speed 2.4kbps-33.6kbps
Compression MH/MR/MMR/JBIG
Communication Line Public Phone Line, Fax Communication Line
Scanning Speed 2.0 sec (A4/detailed mode)
Shortcut Dial 2,000
Program 400
Group 100
Printer Specifications (Standard)
Type Embedded
CPU MPC7448 867MHz (Shared with copier)
Memory 1GB (Shared with copier)
Print Speed Same as Copy Speed (when using the same original)
HDD 60GB (Shared with copier)
Print Resolution 1,800dpi equivalent ✕ 600dpi
PDL PCL6, PostScript3 Emulation
Protocol TCP/IP, IPX/SPX (NDS), SMB (Net BEUI), LPD, IPP1.1, SNMP, HTTP
Support OS Windows NT4.0 SP6/2000, SP3/XP/XP64bit/Server2003/
Server2003 64bit/ Vista (compatibility in development) or later,
MacOS 9.2(PPD)/X 10.2,3,4/10.4 Intel or later, Unix/Linux
Font PCL 80 fonts
PS 137 fonts
Interface (Standard) 10BASE-T/100BASE-TX/1000BASE-T, Hi-Speed USB
Type Full-Colour Scanner
Scanning Size Max. A3
Scanning Resolution 600/400/300/200dpi
Scanning Speed B/W / Colour 70/70 (300dpi), 55/50 (600dpi)
Main Functions Scan to E-Mail, Scan to FTP, Scan to Box, Scan to SMB, TWAIN
Interface 10BASE-T/100BASE-TX/1000BASE-T
Protocol TCP/IP (FTP, SMB, SMTP)
Support OS Windows 2000, Windows XP
Output Format Single TIFF, Multi TIFF, JPEG, PDF, Compact PDF
Driver TWAIN (2000 / XP/ XP 64bit or later)
Type Console
Colour Support Full-Colour
Copy Resolution Scan 600dpi
Print 1,800dpi equivalent ✕ 600dpi
Gradation 256
Memory Capacity (Std/Max) 1GB
HDD 60GB (Standard)
Original Type Sheets, Books, Objects (Max. 2kg)
Max. Original Size A3
Max. Paper Size A3 Wide (12 1/4" ✕ 18")
Output Size A3SEF-A5, B6SEF, A3 Wide (311 ✕ 457mm),
A6SEF Thick Paper, Postcard (100 ✕ 148mm)
Image Loss Top: 4.2mm or less, Bottom: 3mm or less, Sides: 3mm or less
Warm-Up Time (time from when sub-power is turned on) 30 sec. or less
First Copy Time Colour 6.5 sec. or less
(23°C, std. voltage) B/W 4.3 sec. or less
Copy Speed Colour 45 ppm
B/W 55 ppm
Copy Magnification Fixed Same Magnification 1:1±0.5% or less
Scaling Up 1:1.154 / 1.224 / 1.414 / 2.000
Scaling Down 1:0.866 / 0.816 / 0.707/ 0.500
Preset 3 custom settings
Zoom 25 - 400% (in 0.1% increments)
Paper Capacity Std. 500 sheets (Top Tray), 500 sheets (Middle Tray), 1,500 sheets (Bottom Left Tray),
(80g/m 2 paper) 1,000 sheets (Bottom Right Tray), 150 sheets (Multiple Bypass Tray)
Paper Weight Top Tray, Middle Tray, Bottom Tray: 64- 256g/m 2
Multiple Bypass Tray: 64- 300g/m 2
Multiple Copy 1- 9,999 sheets
Power Requirements AC220-240V 10A (50Hz)
Max. Power Consumption 2.0kW or less
Dimensions [W] ✕ [D] ✕ [H] 650mm ✕ 904mm ✕ 1,155mm
Weight Approx. 190kg
Space Requirements [W] ✕ [D] 1,150mm ✕ 1,358mm * Multiple Bypass Tray opened
Fax Kit FK-502
Allows the C550 to perform fax functions.
Image Controller IC-409
Video Interface Kit VI-504
Finisher FS-517
This reliable and speedy finisher allows you to
sort and multi-staple sets of up to 50 sheets.
Punch Kit PK-512
Attach to Finishers FS-517
or FS-608 for hole
punching capability.
Output Tray OT-503
Side Paper Deck LU-301
Increases the C550’s paper
capacity by 3,000 sheets
(A4, 80g/m
2 ).
Finisher FS-608
This high-performance finisher performs the
same functions as the FS-517 and it gives you
the ability to saddle stitch up to 20 sets of
booklets at once. (Max. 20 sheets for each
booklet)
Working Table
WT-502
Post Inserter PI-503
These input trays allow you
to include cover sheets or
chapter break sheets
simultaneously.
FS-608 FS-517
Fiery Image Controller Specifications (Optional)
Type Embedded Type
CPU Intel Celeron 2.8GHz
Memory 512MB
HDD 80GB
Print Speed Same as Copy Speed (when using the same original)
Resolution 1,800dpi equivalent ✕ 600dpi
PDL Adobe PostScript3 ver.3017, PCL6
Protocol TCP/IP(Port9100, LPD, HTTP/HTTPS, SNMP), IPX/SPX, SMB, Ethertalk
Support OS Windows 2000/XP/Server 2003, Mac X(10.3.9/10.4)
Std. Fonts 136 fonts
Interface 10BASE-T/100BASE-TX/1000BASE-T
Product appearance, configuration and/or specifications
are subject to change without notice.
The Konica Minolta logo and the symbol mark, and "The essentials of
imaging" are registered trademarks or trademarks of Konica Minolta
Holdings, Inc.
bizhub, PageScope, Simitri and the Emperon logo are registered
trademarks or trademarks of KONICA MINOLTA BUSINESS
TECHNOLOGIES, INC.
Windows is a registered trademark of Microsoft Corporation in the
United States and other countries.
Adobe and PostScript are registered trademarks or trademarks of
Adobe Systems Incorporated.
All other brand and product names are registered trademarks or
trademarks of their respective owners.
Konica Minolta copiers and multi-functional
peripherals are designed with the environment in mind.
This product has earned the ENERGY STAR for energy efficiency.
ENERGY STAR is a U.S. registered mark.
Requirements for safe use
• Please read and follow the instruction manual to ensure safe
operation.
• Only operate using appropriate power supply and voltage.
• Connecting the earth wire to an inappropriate place may cause
explosion or electric shock. Please connect accordingly (Taiwan and
the Philippines only).
Have Earned ENERGY STAR for Energy Efficiency
The Use of Recycled Materials
Production at ISO-Certified Factories
This product complies with the security requirements
of ISO15408 (EAL Level 3).
*
The ISO 15408 certification applies only to IT security
capabilities. This certification is NOT a product guarantee.
ISO15408 (EAL Level 3) Certification
Local Interface Kit EK-603 (USB Host)
