Thermometer and Hygrometer
1. Once the device is turned on, the display will
show the current temperature and humidity.
2. Press DOWN to change the temperature unit.
3. The device will check the temperature every
hour and compare it to the previous hour.
The results are shown in the temp trend box.
There is one for indoors and one for outdoors.
a. If the temperature has increased,
an arrow that curves up will show.
b. If there is no change in temperature,
a straight arrow will show.
c. If the temperature has decreased,
an arrow that curves down will show.
4. If the device does not receive a signal from
the outdoor transmitter within a hour’s time,
the display will show “--.-”. Once it receives
a signal, it will renew the outdoor display.
5. The indoor humidity are summarized by the
Comfort Indicator.
a. If the humidity is lower than 40% (too dry),
then a “comfortable” icon (non-smiling
face) will appear on the display.
b. If the humidity is more than 70% (too humid),
then an “uncomfortable” icon (frowning face)
will appear on the display.
c. If the temperature is between 20-28° C and the
humidity is between 40% to 70%, then it will
show a “very comfortable icon” (smiling face).
d. If the temperature is outside 20-28° C
and the humidity is between 40% to
70%, nothing will be shown.
6. The weather forecasts have four display icons:
Sunny (sun display), Slightly Cloudy (sun/
cloud display), Cloudy (clouds only display)
and Rainy (clouds with rain display).
Transmitter Setup
1. NOTE: The outdoor, waterproof Transmitter
checks the current temperature and humidity
and every 60 seconds sends the information
to the main Weather Station receiver.
2. NOTE: The Transmitter’s working temperature
is between -4° F to 158° F (20° C to 70° C).
If the Transmitter’s temperature becomes
either lower or higher than these ranges,
the Transmitter will stop working.
3. NOTE: The Transmitter’s humidity range is
between 20% to 95%. If the humidity is lower
than 20%, the display will continue to show
“20%”. If the humidity is higher than 95%, it will
continue to show “95%” in the LCD display.
4. See below for the Transmitter’s display icons:
Transmit
Signal
Battery Power
Indicator
Current
Humidity
Channel
Selection
Current
Temperature
5. To mount the Transmitter, attach the Transmitter’s
holder to a wall or place it on a table.
6. NOTE: Do not mount Transmitter where it will come
into contact with a piece of metal or a highly polished
surface. Doing so can decrease the transmitting range.
7. Use the double-sided tape (not included) to
mount the holder to a smooth surface that
does not allow for screw mounting.
8. The holder can also be mounted to the wall using
screws. NOTE: Verify mounting location is free of any
hidden wires. Once this is done, follow these steps:
a. Use a pen to mark the location of the
mounting holes on the wall.
b. Drill mounting holes in the points marked on the wall.
c. Screw Transmitter holder into wall and
then slide Transmitter into holder.
