9. Start the configuration program, you need to indicate which
serial port is to be used for serial communication by checking
the appropriate check box on the opening menu.
Note:
It is not necessary to know the serial communication
protocol. i.e. baud rate, parity, 7/8 data bit and stop bit; the
program will determine this information automatically.
However, it is good practice to mark the protocols used on the
signal conditioner label if different from default.
10.
Once the program starts it will automatically detect the
signal conditioner configuration and will display a window of
available options. To view the signal input click on the
display on/off.
11.
To change analog output scaling choose analog output
scaling and enter the desired values.
12.
Once the custom scaling is finished, ensure that Send
Configuration is clicked, otherwise the changes will not take
effect.
13.
The input/output scaling may be fine tuned, while both
communication and analog output are active. You may make
a change to the analog output in the configuration program,
and watch the DVM connected to analog output of the signal
conditioner follow the new settings.
14.
You may save or print a particular configuration by
selecting the file menu. ItÕs always a good practice to both
print and save the scaling of each signal conditioner.
15.
If the program is not able to establish communication then
an error message is displayed. This happens either when the
wrong serial port is specified or when the cable is
disconnected.
Power Input and Analog Output Setup:
To connect the signal input proceed as follows:
1.
Connect a DC power supply with an output voltage
between 10 to 32 Volt DC to the signal conditioner (J1).
Note:
If power supply used has current limiting, it may not
be able to power the signal conditioners if the available output
voltage is around 10 Volt, since the peak current may reach 1
to 5 Amp for a few milliseconds.
2.
Determine the maximum current to be measured.
3. Determine the appropriate input connection. i.e. 10 mA,
100 mA have the same input, 1 Amp and 5 Amps have
their own dedicated input. The return is common to all
inputs.
4.
Ensure that if the selected range is different from the default
(5A) then change the internal range by using the Setup
Software and select the appropriate range.
5.
Connect the signal input to screw terminal, and ensure that
the screws are tight. Failure to do so may cause electrical
shock should the wires become loose and come out of the
screw terminal.
6.
To verify that the set up is correct, you may connect a DVM
to the analog output. Once connected, power the signal
conditioner and apply a known current from an AC source to
input. Measure and compare with expected values. To
custom scale the analog output proceed to the next step.
7.
To view/change the scaling that relates the analog output to
signal input: connect the RS232 output of the signal
conditioner to an available serial port of a computer. The
cable and the DB9 or DB25 connectors are available as an
option.
8.
Turn on the computer, start Windows 3.0 or higher and run
the Signal Conditioner Configuration Setup Program. If the
program has not been installed, then insert the 3.5Ó floppy
disk in either drive A or B. From the Program Manager
choose File, Run; in the command box type either A: setup or
B: setup according to your drive designation. The program
will create an icon for the signal conditioner. You may start
the program by clicking on this icon.
5 6
M2522/0201
