ON/OFF Button
Turns the power for the
Main Unit on and off
Bottle Cap Locking Lever
Opens the Medication Bottle for cleaning
Medication Bottle
Holds maximum capacity of 7mL for treatment
Medication Port
Add the medicine to the bottle
®
Electrode
Power conductor from the Main Unit
to the vibrator on the Medication
Bottle
Battery Low Indicator
An orange light blinks when the
batteries
are worn
Power Indic ator
The green ligh t shows the power is on
Main Unit
Bottom of Main Unit
Batt ery Cover
Push lever to
remove
cover
Medicine Bottle Mesh Cap
Metal Alloy Mesh creates
high efficiency aerosol
Mask and Mouthpiece Adapter
Mouthpiece
Main Unit Cover
Protects the Main
Unit with the
attached
Medication Bottle
and
Mesh Cap
during storage Holds the Mouthpiece or Mask
securely on the device
Patient Interface
KNOW YOUR UNIT
Elect rode
Power conductor from the Main
Unit to the AC Adapter
Connection S
tand
