CS-315
CD R ECEIVER S YSTEM
NPR No. 06N47 08/06
Printed in Japan
CR-315 [CD Receiver]
Amplifier Features
• 18 watts per channel minimum into 8 Ω, 1 kHz, JEITA;
25 watts per channel minimum into 4 Ω, 1 kHz, JEITA
• Wide Range Amplifier Technology (WRAT)
• High-current, low-impedance drive
• Discrete output stage circuitry
• Optimum Gain Volume Circuitry
• Direct mode
• 3 audio inputs (1 front panel) and 1 output
• Subwoofer pre out
CD Player Features
• Plays audio CDs and MP3s burnt to CD-Rs and CD-RWs*
• Single-bit DAC
• 4 play modes (Normal/Memory/Random/1 Folder)
• Navigation/All Folder modes for selecting and playing MP3 files
• MP3 settings for personal preferences
• Memory playback (25-track programming)
• 2 repeat modes (Track/Full)
*Discs that have not been properly finalized may only be partially playable or not playable at all.
Tuner & Other Features
• Tone control (bass/treble) via remote
• Super Bass function
• 4-mode timer (Play or Rec/Once or Every)
• Sleep timer
• Preset function with 40 FM/AM selections
• Preset naming (up to 8 characters)
• Manual and automatic FM/AM tuning
• FM auto preset
• Battery-free memory backup
• Aluminum front panel
• FM indoor antenna supplied
• AM loop antenna supplied
• Headphone jack
• Screw-type banana plug-compatible speaker posts
• Compatible with Remote Interactive Dock for the iPod
• RI (Remote Interactive) remote control
D-N7BX [2-Way, Bass Reflex Loudspeakers]
• 13 cm A-OMF Monocoque diaphragm woofer
• 3 cm ring-drive tweeter
• Aero Acoustic Drive for powerful and natural sound
• V-Line Edge to counteract unwanted diaphragm vibration
• Magnetically shielded
• Banana plug-compatible binding posts
• Impedance: 4 Ω
• Max. input power: 70 W
• Frequency response: 50 Hz-100 kHz
*Speaker cable and cork spacers included.
SPECIFICATIONS
A MPLIFIER S ECTION
Power Output .......................................................................................... 18 W + 18 W (8 Ω, 1 kHz, JEITA)
25 W + 25 W (4 Ω, 1 kHz, JEITA)
Dynamic Power ...................................................................................... 22 W + 22 W (3 Ω)
20 W + 20 W (4 Ω)
14 W + 14 W (8 Ω)
Total Harmonic Distortion .................................................................... 0.9 % (Rated Power)
Damping Factor...................................................................................... 25 (Front, 1 kHz, 8
Ω)
Input Sensitivity and Impedance
Line ....................................................................................................... 150 mV/50 k Ω (Tape)
Output Level and Impedance
Rec out ................................................................................................. 150 mV/2.2 Ω
Frequency Response............................................................................. 10 Hz-100 kHz/± 3 dB (Line)
Tone Control............................................................................................ ± 6 dB, 80 Hz (BASS)
± 8 dB, 10 kHz (TREBLE)
+ 7 dB, 80 Hz (SUPER BASS)
Signal-to-Noise Ratio ........................................................................... 100 dB (Line, IHF-A)
Speaker Impedance............................................................................... 4
Ω-16 Ω
T UNER S ECTION
[FM]
Tuning Frequency Range...................................................................... 87.5 MHz-108 MHz
Usable Sensitivity
Stereo/Mono ......................................................................................... 22.2 dBf, 2 µV (75 Ω, IHF)/15.2 dBf, 1 µV (75 Ω, IHF)
Signal-to-Noise Ratio
Stereo/Mono ......................................................................................... 67 dB (IHF-A)/73 dB (IHF-A)
Total Harmonic Distortion
Stereo/Mono ......................................................................................... 0.5 % (1 kHz)/0.3 % (1 kHz)
Stereo Separation.................................................................................. 40 dB at 1 kHz
[AM]
Tuning Frequency Range...................................................................... 522 kHz-1,611 kHz
Usable Sensitivity.................................................................................. 300 dBf (30 µV)
Signal-to-Noise Ratio ........................................................................... 40 dB
Total Harmonic Distortion .................................................................... 0.7 %
CD P LAYER S ECTION
Frequency Response............................................................................. 10 Hz-20 kHz
Audio Dynamic Range .......................................................................... 95 dB
Total Harmonic Distortion .................................................................... 0.009 % (1 kHz)
Wow and Flutter..................................................................................... Below threshold of measurability
Audio Output/Impedance ...................................................................... 1.3 V/1 k
Ω
G ENERAL
Power Supply.......................................................................................... AC 220-230 V, 50/60 Hz
Power Consumption .............................................................................. 56 W
Standby Power Consumption............................................................... 0.25 W
Dimensions (W x H x D) ....................................................................... 205 x 116 x 352.5 mm
Weight...................................................................................................... 4.2 kg
CR-315
D-N7BX
Speaker Type .......................................................................................... 2-Way, Bass Reflex
Drivers
Woofer .................................................................................................. 13 cm A-OMF Monocoque diaphragm
Tweeter ................................................................................................. 3 cm Ring-Drive
Frequency Response............................................................................. 50 Hz-100 kHz
Crossover Frequency............................................................................. 6 kHz
Output Sound Pressure Level.............................................................. 83 dB/W/m
Max. Input Power................................................................................... 70 W
Nominal Impedance .............................................................................. 4
Ω
Dimensions (W x H x D) ....................................................................... 167 x 290 x 246 mm
Weight...................................................................................................... 3.9 kg
Onkyo Corporation 2-1 Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: +81-72-831-8136 Fax: +81-72-833-5222 http://www.onkyo.com/
Onkyo China Limited Unit 1 & 12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road, Kwai Chung, N.T., Hong Kong Tel: +852-2429-3118 Fax: +852-2428-9039 http://www.ch.onkyo.com /
Onkyo U.S.A. Corporation 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: +1-201-785-2600 Fax: +1-201-785-2650 http://www.onkyousa.com /
Onkyo Europe Electronics GmbH Liegnitzerstrasse 6, 82194 Grobenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/
Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance without notice. iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
WRAT is a trademark of Onkyo Corporation. All other trademarks and registered trademarks are the property of their respective holders.
