SPECIFICATIONS
1. All channels driven, continuous 4W load 20Hz to 20kHz, < 0.05% THD, with input voltage
at 13.8VDC.
2. All channels driven, continuous 2W load 20Hz to 20kHz, < 0.1% THD, with input voltage at
13.8VDC.
Amplifier Section Orion 2002 Orion 3002
Power Output 4W Stereo (Watts) 50 x 2 75 x 2
Power Output 2W Stereo (Watts) 100 x 2 150 x 2
Power Output 4W Mono (Watts) 200 x 1 300 x 1
Distortion - all channels < 0.1% THD+N < 0.1% THD+N
driven at rated power
(20Hz to 20kHz)
Frequency Response 20Hz to 20kHZ 20Hz to 20kHZ
±0.25dB ±0.25dB
Linear Bandwidth 10Hz to 50kHz ±3dB 10Hz to 50kHz ±3dB
Signal-to-Noise Ratio > 100dB > 100dB
at Rated Power
Damping factor > 200 > 200
Slew Rate > 20V per msec > 20V per msec
RCA Input Sensitivity 200mV to 5V 200mV to 5V
High Level Input Sensitivity 1V to 10V 1V to 10V
Input Impedance 10kW 10kW
Fuse Type 1 x 25 Amp ATC 1 x 30 Amp ATC
Dimensions 12.4" x 10.5" x 2.4" 15.2" x 10.5" x 2.4"
Weight 7 lbs. 9 lbs.
Crossover Section
Low Pass Crossover Continuously Variable Continuously Variable
2nd Order 2nd Order
(12dB per octave) (12dB per octave)
Low Pass Frequency Range 20Hz to 3kHz 20Hz to 3kHz
High Pass Crossover Continuously Variable Continuously Variable
2nd Order 2nd Order
(12dB per octave) (12dB per octave)
High Pass Frequency Range 20Hz to 3kHz 20Hz to 3kHz
INTELLi Bass 16dB boost 16dB boost
INTELLi Bass Center Frequency 45Hz 45Hz
