SPECIFICATIONS
Model/Part Number
XTRPRO102
XTRPRO104
XTRPRO122
Thiele/Small Parameters
Fs (free-air resonance, Hz)
28.0
32.1
30.5
Vas (equivalent compliance, cu. ft.)
0.681
0.587
1.198
Vas (equivalent compliance, liters)
19.300
16.630
33.950
Qms (Q, mechanical)
5.00
5.12
6.02
Qes (Q, electrical)
0.48
0.54
0.62
Qts (total driver Q)
0.44
0.49
0.56
Re (DC resistance, ohms)
4.1
7.2
4.1
Z (nominal impedance, ohms)
4
8
4
Le (inductance, mh)
2.03
3.00
2.06
Efficiency (1W @ 1M, dB)
81.3
81.9
83.7
Efficiency (2.86 V @ 1M, dB)
84.7
82.7
87.2
Xmax (one way linear excursion, in.)
0.702
0.702
0.702
Xmax (one way linear excursion, mm)
17.825
17.825
17.825
Pe (continuous power handling, watts)
500
500
500
Peak power handling (music, watts) *
1000
1000
1000
Mms (total moving mass, grams)
190.65
168.39
244.17
Cms (mechanical compliance, mm/N)
0.170
0.146
0.112
Bl (motor strength, Tesla-M)
16.85
21.23
17.05
Sd (effective radiating area, sq. cm.)
283.529
283.529
463.770
Sd (effective radiating area, sq. m.)
0.028
0.028
0.046
Sd (effective radiating area, sq. in.)
43.964
43.964
71.912
Frequency range (Hz)
28 - 500
32.1 - 500
30.5-500
Energy Bandwidth Product (EBP) **
58
59
49
Driver Physical Dimension
Speaker Displacement (cu ft)
0.068
0.068
0.091
Mounting hole diameter (inches/mm)
8.85/225
8.85/225
10.91/277
Mounting depth (inches/mm)
5.86/149
5.86/149
6.45/164
Magnet Weight (Oz)
96.00
96.00
96.00
Basket diameter (inches/mm)
10.23/260
10.23/260
12.28/312
Recommended Enclosures
Typical sealed enclosure (cu. ft.)
0.75
0.75
1.50
Vented enclosure (cu. ft.) ***
0.75
0.75
1.50
Port tuning frequency (Hz)
44.00
44.00
40.00
Port diameter (inside, inches)
3.00
3.00
4.00
Port square equivalent (inches)
2.659 x 2.659
2.659 x 2.659
3.545 x 3.545
Port length (inches)
11.19
11.19
11.26
Specifi cations are subject to change without notice
