Onkyo COOLPIX 5100 - Manual (Page 116)

106
T
e
chni
ca
l Note
s
Specifications
Type E5100 digital camera
Effective pixels 5.1 million
CCD 1/2.5” high-density CCD; total pixels: 5.1 million
Image size (pixels)
2,592 Ч 1,944 (2592)
2,048 Ч 1,536 (2048)
1,024 Ч 768 (1024)
640 Ч 480 (640)
Lens 3 × Zoom Nikkor
Focal length
F=5.8 - 17.4 mm
(35-mm [135] camera-format equivalent: 35 - 105 mm)
f/-number f/2.8 - f/4.9
Construction Seven elements in six groups
Digital zoom 4 × (35-mm [135] camera-format equivalent: 420 mm)
Autofocus (AF)
Contrast-detect through the lens (TTL) AF, with AF-assist illu-
minator
Focus range 30 cm (1´) -
∞; macro mode 4 cm/1.6” (W) - ∞
Focus-area selection Center with five-area selection in frame assist mode
AF-assist illuminator
CLASS 1 LED PRODUCT (IEC60825-1 Edition 1.2
-2001
)
Maximum output: 1200 µW
Viewfinder Real-image zoom viewfinder with LED indication
Magnification 0.34 - 0.94 ×
Frame coverage Approximately 76% horizontal and 76% vertical
Monitor 1.6”, 80,000-dot, amorphous silicon TFT LCD monitor
Frame coverage
(shooting mode)
Approximately 96% horizontal and 96% vertical
Storage Media Internal memory (14.5 MB)/SD memory cards
File system
Compliant with Design Rule for Camera File System
(DCF), Exif 2.2, and Digital Print Order Format (DPOF)
File formats Compressed: JPEG-baseline-compliant, Movies: QuickTime
Exposure
Metering
256-segment matrix metering linked to AF area
(when frame is displayed in frame-assisted scene mode)
Exposure control
Programmed auto exposure with exposure compensation
(-2.0 - +2.0 EV in steps of 1/3 EV)
Range
W: +1 - +17.8 EV
T: +2.6 - +16.2 EV
Shutter Mechanical and charge-coupled electronic shutter
Speed 4 - 1/3,000 s
Aperture Electronically-controlled preset aperture
Range Two steps (f/2.8 and f/5.6 [W])
Sensitivity
Approximately equivalent to ISO 50
(auto gain of two to four times) (up to equivalent of ISO200)
Self-timer Ten-second duration
