Voltage Jumper Pin Settings
Figure 3-1 shows the location of solder jumpers W1 through W3.
Figure 3-1. Power Jumper Locations
P3
P1
W1
W2
W3
2
1
2
3
1
TRANSFORMER
SPAN
DISPLA
Y
ZERO
(COMPONENT SIDE)
P2
2
3
1
3
4
S2
S3
S4
S5
AC VOLTAGE
INSTALL
REMOVE
115VAC
W1, W3
W2
230VAC
W2
W1, W3
