Specifications
Image sensor:
1/4" Samsung CCD
Horizontal Resolution: 500 TV Lines (Color), 570 TV Lines (B/W)
Min. Illumination
0.7 Lux (Day/Color), 0.02 Lux (Night/B&W)
Pan Speed:
0-360° /s
Tilt Speed:
0-180° /s (Autoflip), 0-95° /s (Normal)
Optical Zoom:
10X
Digital Zoom:
10X
Pixels:
768 x 494
SN Ratio:
> 50db
Power:
12VDC 750ma (included)
Gain Control:
Auto/Manual
Back Light
Compensation:
Auto/Manual
Lens:
3.8 ~ 38mm, F1.8
Pan:
360 degrees continuous pan rotation
Preset Positions:
127
Comm Port:
RS485 Pelco-D, Pelco-P selectable
Dimensions (mm):
Dome = 100.5mm (Diam)
Housing = 141mm (Diam) 140mm (Height)
Dimensions (inches):
Dome = 3.96in (Diam)
Housing = 5.56in (Diam) 5.51in (Height)
Operating
Temperature:
0C ~ 40C (22F ~ 104F)
Weight:
1.5kg (about 3.5lbs)
Power Consumption: 9W Max
