5. K/J T1 Input Thermocouple Type Select
(Main display)
The K/J key selects the T1 thermocouple type, when the
main display is showing T1. When the thermometer is
turned on, it is set to the type selected when the ther-
mometer was last turned off.
6. MIN MAX with Time record mode
(Main display)
Press MIN MAX key to enter the MIN MAX Recording
mode, (displays the Maximum reading with time, Mini-
mum reading with time and Average reading stored in
record mode). In the this mode the automatic power-off
feature is disabled and key, °C/°F key, REL key,
SET key, Hi/Lo Limits key, K/J, C.J. TEMP and Recall
keys are disabled. The beeper emits a tone when a new
minimum or maximum value is recorded. Present tem-
perature reading displayed on second display. Press MIN
MAX key to cycle through the MAX, MIN and AVG
readings. If an overload is recorded, the averaging func-
tion is stopped. In this mode, press the HOLD key to stop
the recording of readings, all values are held, press again
to restart recording.
To prevent accidental loss of MIN, MAX and AVG data,
this mode can only be cancelled by pressing and holding
the “MIN/MAX” key for 2 seconds. All recorded read-
ings are erased.
7. REL Relative mode (Main display)
Press REL key to enter the Relative mode, zero the dis-
play, and store the displayed reading as a reference value
and annunciator REL is displayed. Present temperature
reading displayed on second display. Press REL key
again to exit the relative mode. The relative value can
also be entered by the user. (See “SET mode” later in this
manual.) When the desired Relative value has been en-
tered, press REL key to enter the Relative mode, press
SET key use set Relative value as a reference value. Press
REL key again to exit the relative mode. In the Relative
mode, the value (can not >±3000.0 counts) shown on the
LCD is always the difference between the stored refer-
ence and the present reading.
8. Sec. Minu. Selecting the Time scale
Press this key to display the elapsed time on the third
display in either hours and minutes or minutes and sec-
onds. When the thermometer is turned on, it is set to
seconds. To change the time scale, press sec. Minus. key.
Maximum elapsed time reading is 100 hours. If 100
hours is exceeded, the elapsed time resets to zero.
9. SET mode (Relative value set, Time set and
Hi/Lo Limits value set)
9.1 Press the “SET” key to enter relative values SET
mode (Press “ENTER” key to skip setting relative
value). = = = =.= is displayed on the main display.
The relative value is entered via overlay numbers,
press overlay “ENTER” key to store the relative value,
and advance to elapsed time set mode.
9.2 Elapsed time set mode, (Press ENTER key to skip
Elapsed time set mode) =.= = = : = = is displayed in
second and third display. Time (hours, minutes, sec-
onds) value is entered via overlay numbers, press
overlay “ENTER” key to store time value. Elapsed
time starts from set time value.
9.3 Hi Limit value set mode, is displayed (Press
“ENTER” key to skip Hi Limit value set mode), = = =
=.= is displayed in main display, Hi Limit value is
entered via overlay numbers, then press “ENTER”
key to store the Hi Limit value. = = = =.= is displayed
in main display, Lo Limit value is entered via overlay
numbers, then press overlay “ENTER” key to store
the Lo Limit value and exit SET mode.
9.4 When the thermometer is turned on it uses the relative
value and Hi/Lo Limits values that were entered when
thermometer was last in use.
10. Relative value Recall display mode.
Press REL RECALL key to display the Relative set value
on second display. Press REL RECALL key again to exit
this mode.
11. Hi/Lo Limits value Recall display mode
Press Hi/Lo RECALL key to display the Hi set Limit
value on second display. Press Hi/Lo RECALL key again
to display the Lo Limits set value on second display.
Press Hi/Lo RECALL key again to exit this mode.
12. Hi/Lo Limits mode (Main display)
Press “Hi/Lo Limits” key to enter the Hi/Lo Limits com-
parative mode, is displayed. When the input tem-
perature value exceeds the Hi or Lo Limits value, the
beeper emits a continuous or pulsed tone. Press “Hi/Lo
Limits” key again to exit the Hi/Lo Limits mode.
OPERATOR MAINTENANCE
WARNING
To avoid possible electrical shock, disconnect the
thermocouple connectors from the thermometer before
removing the cover.
Battery Replacement
1. Power is supplied by 4pcs 1.5V (AAA SIZE) UM-4
R03.
2. The “ ” appears on the LCD display when replace-
ment is needed. To replace battery remove screw from
back of meter and lift off the battery cover.
3. Remove the battery from battery contacts and replace.
4. When not in use for long periods remove battery.
5. Do not store in locations with high temperatures, or
high humidity.
Cleaning
Periodically wipe the case with a damp cloth and deter-
gent, do not use abrasives or solvents.
*Software Operation manual is on the Software disk.
