4CH STANDALONE DVR
-8-
(1)Range: 0-24 hrs.
(2)Set ”T” for continuous recording.
(3)Set “M” for motion recording.
(4)Set up ”-” to disable the recording.
RECORD SCHEDULE
RECORD SCHEDULE
MOTION SETUP
MOTION SETUP MENU
CHANNEL-1 SENSITIVITY 0 (OFF)
CHANNEL-2 SENSITIVITY 0 (OFF)
CHANNEL-3 SENSITIVITY 3 .
CHANNEL-4 SENSITIVITY 5 .
Press to select items, use to enter.
Press to exit
( ):SELECT ( ):SET ( ):EXIT
Press to select items, use to enter.
Press to exit
6、VIEW CONTROL
(1)You can use the following view control buttons to monitor the video from the cameras.
(2)View Control is only valid while the RECORD MODE is in the EACH MODE.
QUAD Display, Enable / Disable theAuto switching function.
Camera #1 (Ch1), return to Quad Mode by press again.
Camera #2 (Ch2),return to Quad Mode by press again.
Camera #3 (Ch3),return to Quad Mode by press again.
Camera #4 (Ch4),return to Quad Mode by press again.
TTTTTTTTTTTTTTTTTTTTTTTT
: : : : : : : :
0 3 6 9 12 15 18 21
★ Please finish
the setup procedure a. and b.
a. Set SENSITIVITY in the menu option
“MOTION SETUP MENU"
b. Set “PROGRAMMED RECORD” --- “M” in the menu
option “RECORD SCHEDULE”.
If you want to enable Motion Recording,
