Sylvania 6413CTC User Manual

Owner’s manual, 6413ctc, 6419ctc

background image

This TV can receive C1 and C2 of Caption and Text.

Caption Mode

(1) Characters can be displayed on the TV screen when the received broadcast signal contains the

Caption Signals.

(2) Paint-on mode: Displays input characters on the screen immediately.

Pop-on mode: Once characters are stored in memory, it is displayed all at once.
Roll-up mode: Displays the characters continuously by scrolling (max. 4 lines)

Note: If the CAPTION C1 or C2 is selected but the caption signal is not included, characters will
not be displayed.

Text Mode

(1) Displays the text on the screen by scrolling (max. 7 lines)
(2) If the received broadcast signal does not contain the caption or text signal, no change will

occur.

Notes:
(1) When your TV receives a special effects playback signal (i.e., Search, Slow, Still) from a

VCR’s video output channel (CH3 or CH4), your TV may not display the correct caption or
text.

(2) Captions and texts may not match the TV voice exactly.
(3) Interference may cause the closed caption system not to function properly.
(4) The caption or text characters will not be displayed while the menu display or function’s dis-

play is shown.

(5) If you see this screen!!

If your TV displays a black box on the screen, this means that your TV is set to TEXT mode. To
clear screen, select CAPTION C1, C2 or CAPTION [OFF].

ANTENNA/CABLE CONNECTIONS

PRECAUTION

Place your TV in a room with adequate ventilation.

Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.

Do not place your TV on soft surfaces, such as rugs or blankets.

Leave enough room for air to circulate around the bottom, top and back of the set.

FEATURES

Tinted, Bright Black Matrix Picture Tube

181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.

PLL Frequency Synthesized Tuning- The latest PLL frequency synthesized electronic tun-
ing system provides free and easy channel selection, and lets you tune directly to any channel
using the channel number buttons (0~9 and +100-key) on the remote control.

On-Screen Function Display.

Full-Function Remote Control

Sleep Timer

Closed Caption Decoder- You may view specially labeled (cc) TV programs, movies, news,
prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

Auto Shut Off Function- If there is no air signal input from the antenna terminal and no
operation for 15 minutes, the TV will turn itself off automatically.

V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.

COLOR TELEVISION

6413CTC

(13 inch)

6419CTC

(19 inch)

Date of Purchase
Dealer Purchase from
Dealer Address

Dealer Phone No.
Model No.
Serial No.

The serial number of this product may be found on the back of the TV. No others have the same
serial number as yours. You should record the number and other vital information here and retain
this book as a permanent record of your purchase to aid identification in case of theft.

ANT.IN

CLOSED CAPTION

UHF
Antenna

(Not supplied)

VHF
Antenna

(Not supplied)

VHF/UHF Combiner
(Not supplied)

VHF/UHF
Combination Antenna
(Not supplied)

UHF/VHF Rod
Antenna

(Supplied with 13
inch model only)

OR

OR

ANT. IN

OUT

IN

75-ohm
Coaxial Cable

From Cable System

From Cable System
or Satellite Antenna
75-ohm
Coaxial Cable

CATV Box

*

or Satellite Box
(Not supplied)

*

Some cable TV systems use scram-

bled signals and require a special con-
verter to receive these channels.
Consult your local cable company.

IF YOU NEED ADDITIONAL ASSISTANCE FOR SET-UP OR OPERATING
AFTER READING OWNER’S MANUAL, PLEASE CALL TOLL FREE
1-800-287-4871.

Owner’s

Manual

0EMN01879

Printed in Malaysia

L6002CC/L6102CC * * * * *

This Owner’s Manual is made of recycled paper.

CAUTION: TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY
INSERT.

Before plugging the UHF/VHF Rod
Antenna into the ANT(enna). IN jack, check
that the pin is not bent. If it is bent, straight-
en the pin as illustrated, then plug the pin
into the ANT(enna). IN jack.
(Rod Antenna is included in 13 inch model
only)

Bent pin

Cable

Plug

(Needs to be straightened)

(Straight pin)

NOTE:CHANNEL SET UP MUST BE COMPLETED BEFORE THE SET WILL FUNC-

TION PROPERLY. SEE INSIDE FOR PROCEDURE.

SYLVANIA HOME ENTERTAINMENT WARRANTY

We appreciate your purchase of a SYLVANIA Home Entertainment product. We take pride in the quality of our
products and have manufactured your new Home Entertainment unit to exacting quality standards. We feel
confident that in normal use, it will provide you with satisfactory performance. However, should you experience
difficulty, you are protected under the provisions of this warranty.
SYLVANIA Home Entertainment products are warranted against manufacturing defects in materials and
workmanship in normal use for the following periods from the date of purchase by the original user, and is
conditional upon the unit being installed and used as directed in the instruction manual.

Product

Labour

Parts

Picture Tube

Colour Televisions

1 Year

1 Year

3 Years

Remote Control

90 Days

90 Days

B/W Televisions

90 Days

1 Year

1 Year

SYLVANIA s obligation under this warranty shall be limited to the repair, including all necessary parts and the
cost of the labour connected therewith, or at our option the exchange of any Home Entertainment product which
shows evidence of a manufacturing defect within the warranty period.
Replacement parts, furnished in connection with this warranty shall be warranted for a period equal to the
unexpired portion of the original equipment warranty.

CUSTOMER OBLIGATIONS

This warranty applies to the product from the original date of purchase at retail. Therefore, the owner must
provide a copy of the original, dated bill of sale. No warranty service will be performed without a bill of sale.
Transportation to and from the service depot is the responsibility of the owner.

WARRANTY EXCLUSIONS

This warranty is extended to SYLVANIA Home Entertainment products purchased and used in Canada. This
warranty shall not apply to appearance or accessory items including but not limited to: antenna, cabinet, cabinet
parts, knobs, batteries, connecting cables. This warranty shall, in addition, not apply to damages due to
handling, transportation, unpacking, set-up, installation, customer adjustments that are covered in the instruction
book, repair or replacement of parts supplied by other than the SYLVANIA authorized service depot, any
malfunction or failure caused by or resulting from abnormal environmental conditions, improper unauthorized
service, improper maintenance, modifications or repair by the consumer, abuse, misuse, neglect, accident, fire,
flood, or other Acts of God, and incorrect line voltage. This Home Entertainment product is only warranted to
the original retail purchaser. This warranty becomes void in the event of commercial or rental use. This warranty
becomes void in the event serial numbers are altered, defaced or removed. SYLVANIA reserves the right to make
changes in design or to make additions to or improvements upon this product without incurring any obligation
to install the same on products previously manufactured. The foregoing is in lieu of all other warranties
expressed or implied and SYLVANIA neither assumes nor authorizes any person to assume for it any other
obligation or liability in connection with the sale or service of this product. In no event shall SYLVANIA or its
SYLVANIA dealers be liable for special or consequential damage arising from the use of this product, or for any
delay in the performance of this warranty due to cause beyond our control.
The purchaser may have other rights under existing provincial or federal laws, and where any terms of this
warranty are prohibited by such laws, they are deemed null and void, but the remainder of the warranty shall
remain in effect.

HOW TO OBTAIN SERVICE

Should this product require service, you may obtain specific information on how to obtain service by contacting
the SYLVANIA Dealer from whom this product was purchased, or by contacting us directly:

SONIGEM SERVICE

300 Alden Road

Markham, Ontario

L3R 4C1

PHONE: (905) 940-5089 FAX: (905) 940-2303

1-800-287-4871

L6002/6102.QX33 01.11.2 10:01 AM Page 1
