background image

GPS-6036 Operating Manual

Rikaline

Rikaline

International Corp.

14F, 171, Chen-Gong Road, SanChong City, Taipei 241, Taiwan

Tel: ++886 2 8973 1899 Fax: ++886 2 8973 1896 E-Mail:

[email protected]

Web: www.rikaline.com.tw

17

Appendix C Detailed Specifications

C.1 Bluetooth Specifications

C.1.1 Major Specification

Specifications

Wireless Interface

Compliant with Bluetooth Spec. Version 1.2

Bluetooth Protocol Stack Supported All + Extended SCO
Bluetooth Profiles Supported

SPP

Frequency

2.4 GHz license-free ISM band

Range (Open Environment)

Up to 10 meters Range (30ft)

Radio Receiver Sensitivity

<-85

C.2 LED status

NO. Function

Description

1 PWD

ON:

Recharging

ON: Power On
Blinking: Battery Low

2

BT

OFF: Data Transmitting
ON: Standby
ON.: Pairing

3

GPS

ON: Position is fixed
OFF: Not Powered
Flash: Position is not fixed


C.3 Battery

C.3.1 General Specification

ITEM

SPECIFICATION

1

Type

Li-ION Rechargeable Battery

2 Model

A-9007

3 Typical

Capacity

740

mAh

4

Nominal Voltage

3.7 V

5

Internal Resistance (packed)

30 – 70mΩ

6

Weight

Approx 19 g

7

Maximum Charge Current

1.0 C (1000 mA)

8

Charge Voltage

4.20 ± 0.05 V

9

Maximum Discharge Current

1.0 C

10

Charge method

CC/CV

11 Temperature

For Recharge
For Discharge

0 ~ 45 °C

-20 ~ +60 °C

12 Storage

Temperature

Within 1 month
Within 3 months
Within 1 year


-20~+65 °C*
-20~+45 °C*
-20~+25 °C*


C.3.2 Testing Data

C.3.2.1 Electrical Characteristics

NO ITEM

TESTING

INSTRUCTION

REQUIREMENTS

1

Complete

Charge

Charge the battery with 1c of constant current and 4.2V
constant voltage for 2.5 hours.

2

Nominal

Measure discharge capacity with discharge current 0.2C to 2.75V 703mAh
