Rose electronic DVI-D - Manual

RackView
LCD
W W W . R O S E . C O M
Rack mounted TFT/LCD Monitor
1U 1U 1U 1U ---- High resolution TFT/LCD monitor High resolution TFT/LCD monitor High resolution TFT/LCD monitor High resolution TFT/LCD monitor
HD15, DVI, and S HD15, DVI, and S HD15, DVI, and S HD15, DVI, and S----Video/composite Video/composite Video/composite Video/composite
connectors (Depending on model) connectors (Depending on model) connectors (Depending on model) connectors (Depending on model)
Needs only 1U of rack space Needs only 1U of rack space Needs only 1U of rack space Needs only 1U of rack space
Available in 15", 17", and 19" Available in 15", 17", and 19" Available in 15", 17", and 19" Available in 15", 17", and 19"
(Also a 20" panel mount model)
(Also a 20" panel mount model) (Also a 20" panel mount model) (Also a 20" panel mount model)
Features and Benefits
Four sizes to choose from:
15" LCD
17" LCD
19" LCD
20” LCD panel mount
19" model features HD15 and DVI-D inputs or
HD15 and S-Video / Composite inputs
PiP features using two different video inputs
optional on the 20” model
Front panel controls
On-screen display for adjusting all settings
Provides a sharp, clear display
Easy to install
Optional KVM or Video switch can be added
Made in USA
The RackView™ Advantage . . .
The RackView Monitor models are an innovative space
saving design that fits in 1U of rack space.
It can be placed at any height within a standard 19" rack.
This offers the operator the maximum viewing comfort
and takes up a minimum amount of rack space. The front
panel conceals the unit when it is not in use.
The optional KVM switch offers single or multiple user
access to as many as 1,000 servers or computers. A
separate keyboard and mouse are needed to fully utilize
the KVM switch option. Rose Electronics KVM switch
options are fully expandable and when combined with the
RackView, your system becomes a versatile, distributed
matrix controlled system with multi-user capability,
controlled access to the servers, and many other features.
PC's, UNIX, Sun, Apple, and USB computers can easily be
connected and monitored locally using the RackView
monitors.
1U Rackmount monitor
