MAINTENANCE

SWITCH REPLACEMENT

See Figure 16.

1.

Before attempting to replace the switch on your router,
you must know the model of your router (Model No.
R160 or Model No. R165). To replace switch, follow the
steps and illustrations below.

2.

UNPLUG YOUR ROUTER.

3.

Remove screws (A) and handle cover (B).

See Figure

16.

4.

NOTE THE LOCATION OF THE MOLDED BEND
RELIEF (C) ON THE POWER HANDLE CORD. ALSO

NOTE ALL WIRING IN THE HANDLE AND HOW EACH
LEAD IS CONNECTED TO THE SWITCH.
Connections
and wiring position must be identical when installing
new switch.

See Figure 16.

5.

Remove leads from switch (D) by inserting a 1/32 in.
diameter nail or pin into switch lead receptacle and
pulling on lead as shown in figure 16. Remove nail or
pin with a twisting, pulling motion.

6.

Make lead connections to new switch. Push each lead
as far as possible into proper switch receptacle. Pull on
leads to check lead connections with lead receptacles.

7.

Locate switch in handle and place leads so they won't
be pinched or contact screws when handle cover is
replaced.

8.

Make sure molded bend relief (C) is correctly positioned
in switch handle, then replace handle cover and screws.

9.

Tighten all screws securely.

SWITCH REPLACEMENT FOR MODEL NO. R160

SWITCH REPLACEMENT FOR MODEL NO. R165

Fig. 16

WHITE LEAD

A

B

1/32 INCH DIAMETER

NAIL OR PIN

BLACK LEAD

C

D

SWITCH

POWER HANDLE CORD

RED

WORKLIGHT LEAD

WHITE LEAD

1/32 INCH DIAMETER

NAIL OR PIN

BLACK LEAD

SWITCH

RED

WORKLIGHT LEAD

RED POWER

CORD LEAD

WARNING:

Failure to unplug your router could result in accidental
starting causing serious injury.

B

C

POWER HANDLE CORD

D

A
