11
11. Parts List : HM20
Key# Part KIT Number Description Q'ty
1 RMKIT15 Belt and clip. 1
2 RMKIT283 • Belt hook. 2
3 RMKIT36 • Shoulder pad. 1
4 RMKIT17 Hose & 2 hose clamps. 1
5 RMKIT18 Complete spray pistol. 1
6 RMKIT19 • Spindle set. 1
7 RMKIT20 • Spindle O-ring set. 1
8 RMKIT21 • Plug set. 1
9 RMKIT367 • • O-ring for plug. 1
10 RMKIT22 Brass spray wand 20". 1
11 RMKIT25 Spray tip set. 1
12 RMKIT24 • Nozzle holder. 1
13 RMKIT26 • Spray tip O'ring Nytril. 1
14 RMKIT524 Red base for compression sprayer. 1
15 RMKIT0567 Complete pump module. 1
16 RMKIT0566 • Recl pump handle. 1
17 RMKIT54.2 • Pump tube. 1
18 RMKIT55 • • Large pump O'ring. 1
19 RMKIT56 • • Check valve "antenna" & O'ring. 1
20 RMKIT59 • Pump plunger ass'y set. 1
21 RMKIT57 • • Pump plunger. 1
22 RMKIT60 • Pump top screw set. 1
23 RMKIT279 Hose spring for compression sprayer. 1
24 RMKIT392 Washer set for gun and nozzle. 1
