18 M1500 Marine Monitor
6 Specification
7 Accessories
Audio/video Junction Box E85003
Black Dress Panel Kit E05009
Trunnion Mount Bracket Kit E05011
Approvals:
CE - conform to
FCC - conforms to
1999/5/EC, EN60945:1997
Part 80 (47CFR) and Part 2 (47CFR)
Size: 416.4 mm x 334.2 mm x 141.0 mm
(16.4 in x 13.16in 5.55in)
Weight 10 kg (22 lbs)
Mounting Console mount with bracket mount option
Power 12 V and 24 V system (10.7 V to 32 V DC absolute)
Floating earth/fully isolated
72W max. consumption with full brightness
Fuses See Power Connections on page 8 for fuse values.
Environmental:
Operating Temp. Range
Non-operating Temp. Range
Humidity limit Waterproof to CFR46; suitable for external mounting
-10°C to +50°C
-20°C to +70°C
up to 95% at 35°C non-condensing
The display must be stored and installed away from strong
magnetic fields.
Controls Power on/off button
OSD (On Screen Display) control switches
Display Type color TFT LCD
Resolutions and Refresh Rates 640 x 480, 60 Hz
800 x 600, 72 Hz
1024 x 768, 60 Hz (recommended)
1024 x 768, 70 Hz
1280 x 1024, 60 Hz
Display Size 304.1 mm x 228.1 mm active area
Connectors Power Input,
DVI Input,
VGA Input,
Audio Input or
Audio, Composite Video, S-Video Input via the optional audio/
video junction box
Touch Screen Output (if fitted)
