Computer/Video Signal
Compatibility
The CinemaWall can display video signals from a variety of computer sources via its
RGB-HD and DVI inputs.
Table 7-2 lists the signal types that are compatible with the CinemaWall, and indicates
which of those are VESA standards.
Table 7-2. Computer/Video Signal Compatibility Chart
Signal Type
Mode
(Dots x Lines)
Vertical
Frequency (Hz)
Horizontal
Frequency (kHz)
Sync Polarity
Horiz.
Vert.
IBM
640x400
70.10
31.50
neg
neg
IBM
640x480
59.90
31.50
neg
neg
MAC
66.70
35.00
Sync on Green
VESA
72.80
37.90
neg
neg
VESA
75.00
37.50
neg
neg
VESA
85.00
43.30
neg
neg
IBM
100.40
51.10
neg
neg
IBM
120.40
61.30
neg
neg
IBM
720x400
70.10
31.50
neg
neg
VESA
85.10
37.90
neg
pos
VESA
800x600
56.25
35.20
pos
pos
VESA
60.30
37.90
pos
pos
VESA
72.20
48.10
pos
pos
VESA
75.00
46.90
pos
pos
VESA
85.10
53.70
pos
pos
IBM
99.80
63.00
pos
pos
IBM
120.00
75.70
pos
pos
MAC
832x624
74.60
49.70
Sync on Green
IBM
848x480
60.00
31.00
pos
pos
IBM
852x480
60.00
31.70
neg
neg
VESA
1024x768
60.00
48.40
neg
neg
SGI
60.00
49.70
--
--
VESA
70.10
56.50
neg
neg
MAC
74.90
60.20
Sync on Green
VESA
75.00
60.00
pos
pos
VESA
85.00
68.70
pos
pos
IBM
100.00
80.50
neg
neg
IBM
1280x768
56.20
45.10
pos
pos
SGI
1280x1024
60.00
63.90
--
--
IBM
1280x1024
60.00
64.00
pos
pos
Notes:
1. The CinemaWall may not be able to display images from notebook computers in simultaneous
(CRT/LCD) mode. Should this occur, switch the notebook computer to “CRT only” mode. If you
are unsure how to do this, refer to your notebook computer’s user manual.
2. All modes other than the native resolution (1024x768 for the CW-42HD or 1365x768 for the
CW-50XA and CW-61) are scaled up or down to that resolution.
