RCA LCD FLAT PANEL HDTV User Manual
Page 9
Connections and Setup
Chapter 1
9
Step 2
1.
Take the Stand Base, Post Support and 3 Size M4 screws.
2
. Locate the Post Support on the Stand Base by aligning the screw holes.
3.
Attach the Post Support to the Stand Base with 3 Size M4 screws, from the
top, with a screwdriver.
Table Stand Assembly
Step 3
Attach the Table Stand Assembly to the TV cabinet by
inserting the Post Support into the cabinet and aligning the
Post Support Guide to the Slot Opening
Post Support
Guide
Slot Opening
