Raritan Computer Raritan ASMI G4 - Manual (Page 48)

Chapter 6. Menu Options
Figure 6-4. Two Virtual Floppies
Upload a Floppy Image
With two small working steps a (floppy) image can be uploaded.
1. Specify the path of the images. You can pecify up to two images. You can do that either manually or
by using the file selection dialog of your web browser. To open the file selection dialog click on the
button "Browse" and select the desired image file.
Figure 6-5. Select Image File
The maximum image size is limited to 1.44MB. If you want use a larger image then please mount
this image using a Windows Share (or SAMBA).
2. Now click the "Upload" button to initiate the transfer of the chosen image file into the ASMI
module’s on-board memory. This image file is kept in the on-board memory of the ASMI module
until the end of the current session or until you logout or initiate a reboot of the ASMI module.
39
