C HAPTER 1: I NTRODUCTION 1
Chapter 1: Introduction
MasterConsole Z Overview
The MasterConsole Z switchless access system consists of two components – a User Station
(MZUST) and an MZ-Computer Interface Module (MZCIM), connected with Enhanced Category
5e UTP cable. The MZCIMs are linked in a chain via Category 5e UTP cable, and servers are
connected to each of the MZCIMs. Please note that these MZCIMs are not compatible with
P2ZCIMs or ZU4200 CIMs.
With a MasterConsole Z system, you can:
• Add a computer anywhere in the chain at any time
• Hot connect a user console to any server
• Hot-swap components with no impact on server operation
• Select computers by name from on-screen menus
• Locate user up to 700 feet (213m) away with Category 5e UTP cable
Product Photos
Figure 1 MasterConsole Z User Station (MZUST)
Figure 2 MasterConsole Z Computer Interface Module (MZCIM-PS2)
