Roberts Radio Analogue World Radio R9968 - Manual (Page 18)

18
Specifications
Power Requirements
Adapter Output DC 3-6 volts, 200mA
Battery 2 x LR6 (AA Size) alkaline
Frequency Coverage
FM 87.5 - 108MHz
MW 526 - 1710kHz
SW 1 - 7 5.90 - 6.20MHz (49 m)
7.10 - 7.35MHz (41 m)
9.40 - 9.90MHz (31 m)
11.6 - 12.10MHz (25 m)
13.57 - 13.87MHz (21 m)
15.1 - 15.73MHz (19 m)
17.48 - 17.9MHz (16 m)
Circuit Features
Loudspeaker 4 ohms
Output power 100 mW
Antennas
Telescopic antenna FM and SW
Ferrite rod antenna MW
Sockets
Headphones Socket 3.5mm dia.
DC Socket 4.0mm dia. Centre pin negative
