Connecting with Other Optional Equipment

REMOTE CONTROL

• Is the unit plugged into a working power outlet?

Try plugging it into one that you know works then test the remote control.

• Is the battery weak?

Replace the battery with a new one.

• Make sure that you are pointing the remote control at the remote sensor on the unit.

• Are you too far from the unit when using the remote control?

The remote control sensor can only sense a signal from the remote control within 13 feet, so you may need to move closer to the unit.

• Are there any obstacles between the remote control and the unit?

If there are, remove all objects in the way.

CLOCK DOES NOT SHOW CORRECT TIME:

• There was a power outage. Set the clock again as described in "SETTING THE CLOCK".

CLEANING THE UNIT

• Do not use volatile chemicals on this unit. Clean by lightly wiping with a dry soft cloth.

• Keep the CD Drawer closed to keep dust out of the unit.

CLEANING THE CD

• If the CD skips or will not play, the disc may need to be cleaned. Before playing, wipe the disc from the center outwards with a clean cloth. After

playing, store the disc in its case.

HANDLING THE CD

• Only touch the CD on the edge to avoid finger prints on the underside of the CD.

• Do not stick paper or tape on the underside of the CD, and do not write anything on the underside of the disc.

CD LENS CARE

• When your CD lens gets dirty it can cause the unit to output poor sound quality. To clean the lens you will need to purchase a

CD lens cleaner. For instructions on cleaning the CD lens, refer to the instructions accompanying the CD lens cleaner.

Troubleshooting, Care & Maintenance

1. Connect the AC power cord plug to the AC power outlet.

2. Pull the MP3 player docker downwards to the right place.

3. Connect the plug of the Built-in AUX cable to the AUDIO OUT or

Earphone jack of the external equipment.

4. Press the FUNCTION button on the remote control or the

CD

·RADIO·AUX button to change to AUX. The AUX indicator lights up.

5. Turn on your audio equipment and play the external source.

TUNING IN TO A STATION MANUALLY

1. Press the button on the front panel or the POWER button on the

remote to turn on the unit.

2. Press the CD

·RADIO·AUX button on the unit or

the FUNCTION button on the remote control until

TUNER is displayed.

3. Press the AM /FM button on the unit or the

STOP/BAND button on

the remote control to select AM or FM.

4. Press the

/

button to tune in to a desired station.

Note: When using the radio, the station will disappear and the time will be

displayed if no button is pressed within 10 seconds.

To Quickly Search for a Station

Press and hold the

/

button until the tuner starts searching for a

station, then release.

The tuner will stop on the next station.

To Turn Off the Radio

Press the button on the unit (or the POWER button on the remote) to

turn the unit off.

Setting a Radio Station PRESET

The unit can store a total of 20 stations in memory (10 FM, 10 AM).

Presetting allows you to tune in to a station directly.

1. Press the CD

·RADIO·AUX button on the unit or the FUNCTION button

on the remote control to select TUNER.

2. Press the

STOP/BAND button on the remote control or the AM /FM

button on the unit to select AM or FM.

3. Press the

/

buttons to tune in to a desired station.

4. Press the / MEMORY button until the “MEM”

indicator blinks and "P 01" appears on the display.

The "P 01" is the order of the preset station (1-10).

5. Press the

REPEAT/PRESET button to select the preset number.

6. Press the / MEMORY button to store the station.

7. Repeat steps 3 to 6 for the next preset.

TUNING IN TO A PRESET RADIO STATION

1. Press the CD

·RADIO·AUX button on the unit or the FUNCTION button

on the remote control until TUNER is displayed.

2. Press the

STOP/BAND button on the remote control or the AM /FM

button on the unit to select AM or FM.

3. Press the

REPEAT/PRESET button to select a preset station.

Radio

1. Press the TIMER button. The “

” indicator appears.

2. Press the /

buttons to select your desired time from 1-99 minutes.

• Press the TIMER button repeatedly to select time: 10, 15, 30, 45, 60, 75,

90 minutes.

• Press and hold the /

buttons to fast forward/reverse the cooking

time.

3. When the preset time elapses, the ALARM will sound.

4. To turn Off the ALARM, press the TIMER button once. Otherwise, the

ALARM will automatically turn off after 60 minutes if no button is pressed.

Note: Do not press any buttons within 5 seconds after setting the cooking

time, otherwise, the cooking timer will be cancelled.

CANCELLING THE COOKING TIMER
• Press the TIMER button until the time of the cooking timer shows "00".

The “

” indicator will disappear.

Setting the Cooking Timer

CD mode

1. During playback, press the DISPLAY button repeatedly to shuffle

between the CD playback mode and the current time.

2. When stopped, press the DISPLAY button to shuffle between the

total number of CD tracks and the current time.

RADIO Mode

• Press the DISPLAY button to shuffle between the current radio station

and the current time.

Display Function

Listening to the Audio Signals from the External Equipment

CD Playback

CD PLAYBACK

1. Press the button on the front panel or the POWER button on the

remote to turn on the unit.

2. Press the CD

·RADIO·AUX button to change CD

mode.

3. Press the button to open the CD drawer. Place a CD onto the CD

tray with the label side up and then press the button to close it.

The CD will be scanned by the unit and the total # of tracks will be

displayed.

4. Press the

button to start playing the CD. The

current track appears on the display.

Note: During playback, the track number will disappear and the time will

be displayed if no button is pressed within 10 seconds.

• Adjust volume by pressing the VOLUME +/- buttons.

To Pause Playback

• Press the button. The " " indicator blinks.
• To resume playback, press the button again.

To Stop Playback

• Press the

STOP/BAND button.

To SKIP to a Different Track

• To SKIP to the beginning of the PREVIOUS track, or any earlier track,

press the

button.

• To SKIP to the beginning of the NEXT track, or any later track, press

the button.

To FAST FORWARD or FAST REVERSE to a Particular Point

• To scan forward at high speed, press and hold the

button and

release it at the desired point.

• To scan backward at high speed,

press and hold the

button and release it at the desired point.

• Fast forward or Fast reverse will continue searching the CD until it

reaches the end.

CD REPEAT PLAYBACK

Repeating the Current Track

• Press the

REPEAT/PRESET button until “REP” appears, the current

track will be played repeatedly.

• Select a desired different track to be repeated by

pressing the

/

buttons.

Repeat the Entire CD

• Press the

REPEAT/PRESET button until “REP”

blinks.

All tracks will be played repeatedly.

Cancel Repeat Play

• Press the

REPEAT/PRESET button until “REP” disappears.

CD PROGRAMMABLE PLAYBACK

20 tracks can be programmed to play in a preset order.

1. When the unit is ON and in CD MODE, make sure

the CD is STOPPED. Press the / MEMORY button.

“MEM” and “P 01” will blink on the display. The “P 01”

is the program order (1-20).

2. Press the

/

buttons to select the desired

track. For example, to play track 2 first, the display
would look like this:

3. Press the / MEMORY button to store the track in

memory.

4. To add additional tracks, repeat steps 2 - 3 (up to 20 tracks).

5. To start playback, press the

PLAY/PAUSE button.

To check the program:

• After setting, press the

PLAY/PAUSE button to start playing, then

press the /

buttons to check the programmed tracks.

To add additional tracks during program playback:

• Press the

STOP/BAND button, then press the / MEMORY button

repeatedly until the number of the last programmed track appears and

repeat steps 2-4 above.

To change the programmed tracks during program playback:

• Press the

STOP/BAND button, and press the / MEMORY button

repeatedly to select the number of the program, then press the

/

buttons to alter the track. Press the / MEMORY button to register the

newly programmed track into memory.

To erase the whole program, do one of the following:

• Press the

STOP/BAND button twice.

• Press the CD

·RADIO·AUX button to change to radio mode.

• Open the CD drawer by pressing the button.

Note: You can use the REPEAT function during program play.

SETTING THE CLOCK

The unit must be in standby mode. To enter standby mode, make sure

that the unit is plugged in, but not turned on.

1. Press the / MEMORY button until the TIME digit blinks.

2. Press the

button to set the current hour.

3. Press the button to set the current minutes.

4. Press the

/ MEMORY button to start the clock. The clock will

automatically start if no button is pressed within 10 seconds.

Note:12-hour system "12:00 PM" = midnight.

Setting the Clock

LIMITED WARRANTY

AVC MULTIMEDIA ("AVC") makes the following limited warranties.

These limited warranties extend to the original consumer purchaser and

is limited to non-commercial user of the product.

One Year Parts & Labor Warranty

AVC products purchased in the United States are warranted to be free

from defects in materials or workmanship for a period of one year from

the date of their original retail purchase. If the unit fails to conform to this

warranty, we will service the product using new or refurbished parts and

products, at

AVC's sole discretion.

During a period of one year from the effective warranty date,

AVC will

provide, when needed, service labor to repair a manufacturing defect at

its designated Service Center. To obtain warranty service in the United

States, you must first call our

Customer Support Center at 1- 877- 252

- 6873, during the hours listed in the box below. The deternination of

service will be made by AVC customer support.

PLEASE DO NOT RETURN YOUR UNIT TO AVC WITHOUT PRIOR

AUTHORIZATION. New or remanufactured replacements for defective

parts or products will be used for repairs by

AVC at its designated Service

Center for one year from the defective warranty date. Such replacement

parts or products are warranted for an additional one year from the date

of repair or replacement. The Customer will be required to ship the unit to

the Service Center indicated at the time Customer Support is contacted

to make the necessary repairs. The customer is responsible for all

transportation charges to the service facility.

Packaging and Shipping Instruction

When you send the product to the AVC service facility you must use the

original carton box and packing material or an equivalent as designated

by

AVC.

In the event your product requires repair after the limited warranty

period has expired, please contact our Customer Support Center at

1-877-252-6873 or

www.1800customersupport.com/RCA.

Hours: Monday-Thursday: 9am-7pm, Friday: 9am-5pm, Saturday:

9am-NOON Eastern time.
Important:

You are responsible for any transportation, shipping or insurance

relative to the return of the product to our Product Returns Center.

Important:

Also keep your “Bill of Sale” as proof of purchase.

Model no. ........................................ Product name ..................................

Type of set ...................................... Serial no. ..........................................

Invoice no. ...................................... Date purchased ................................

Dealer name ..................................

F O R S E R V I C E A N D R E P A I R , P L E A S E V I S I T

w w w .

1800customersupport.com/RCA

Specifications and external appearance are subject to change without

notice.

Your Responsibility

(1) You must retain your bill of sale to provide proof of purchase.

(2) These warranties are effective only if the product is purchased and

operated in the U.S.A. or Canada.

(3) Warranties extend only to defects in material or workmanship,

and do not extend to any product or parts which have been lost

or discarded, or damage to product or parts caused by misuse,

accident, improper operation or maintenance, or use in violation of

instructions provided with the product, or to product which has been

altered or modified without authorization of

AVC, or to products

or parts thereof which have had the serial number removed or

changed.

Out of Warranty

All warranties implied by state law, including the implied warranties

of merchantability and fitness for a particular purpose, are expressly

limited to the duration of the limited warranties set forth above. With

the exception of any warranties implied by state law as hereby limited,

the foregoing warranty is exclusive and in lieu of all other warranties,

Limited Warranty

guarantees, agreements and similar obligations of manufacturer or seller

with respect to the repair or replacement of any parts. In no event shall

AVC be liable for consequential or incidental damages.

No person, agent, distributor, dealer or company is authorized to change,

modify or extend the terms of these warranties in any manner whatsoever.

The time within action must be commenced to enforce any obligation of

AVC arising under the warranty or under any statute, or law of the United

States or any state thereof, is hereby limited to one year from the date of

purchase. This limitation does not apply to implied warranties arising under

state law.

This warranty gives you specific legal rights and you may also have other

rights, which may vary from state to state. Some states do not allow

limitation on how long an implied warranty lasts, when an action may

be brought, or the exclusion or limitation of incidental or consequential

damages, so the above provisions may not

apply to you.

For more information on other products and services, please contact our

web site at

www.1800customersupport.com/RCA.

Printed in China

811-369991W010
