5 110939
OWNER’S MANUAL
For more information, visit www.desatech.com
STARTING THE POLE
TRIMMER
The Pole Trimmer has a trigger lock button
located on top of the handle. This safety
feature locks the trigger in the OFF posi-
tion, preventing accidental starting of the
Pole Trimmer.
The trigger lock button has three posi-
tions.
Position 1 locks the trigger.
Position 2 allows you to squeeze the trigger
and operate the Pole Trimmer. The trigger
lock button will automatically spring back to
Position 1 when you release the trigger.
Position 3 allows you to lock the trigger
in the ON position. This is helpful during
continuous trimming for extended periods
of time.
Note: An optional method of retaining the
extension cord is shown in Figure 8 for use
with larger-gage cords that may not fit into
the extension cord retainer.
2. Release the trigger lock button while the
Pole Trimmer is running. The lock button
resets to Position 1 each time you release
the trigger to the OFF position.
Figure 9 - Manually Operating Trigger with
Trigger Lock Button in Position 2
Figure 10 - Trigger in OFF Position with
Trigger Lock Button in Position 1
Trigger Lock
Button Position 2
Trigger Lock
Button Position 1
Figure 7 - Extension Cord Loop Tight
Around Molded Cord Hook
Figure 8 - Optional Method of Retaining
Extension Cord
Figure 6 - Inserting Extension Cord Loop
Through Bottom of Handle
Continued
Unlocking the Trigger to Start
the Pole Trimmer
1. Using your thumb, push the trigger lock
button forward to Position 2. Squeeze
the trigger lever to the ON position. The
Pole Trimmer will start running.
3. Create a loop in the extension cord and
insert the loop through the bottom of
the handle. Pull the loop tight around
the molded cord hook (see Figures 6
and 7).
OPERATING POLE
TRIMMER
Continued
