Ricoh GigE Vision VGA Monochrome CCD Camera FV-G200B1 - Manual (Page 8)

8/38
FV-G200B1
User’s Guide Rev. 1.02
2.2.2 1/2 Partial Scanning
1 H = 52.1472 μs, 30.63336 Hz
2.2.3 1/4 Partial Scanning
1 H = 52.1472 μs, 61.26674 Hz
232H
Video out
Vertical blanking
313H
One vertical (1V)
232H
81H 81H
Video output
7
3
3
7
3
4
5
0
3
5
0
4
FVAL
81H 81H
LVAL
DVAL
570H
Video out
Vertical blanking
626H
One vertical (1V)
56H 56H
Video output
9
0
2
9
0
3
3
3
4
3
3
5
FVAL
570H 56H 56H
LVAL
DVAL
