PART IDENTIFICATION CHART

Use the chart below to identify the small parts used in
assembly. The number in parenthesis below each part
is the key number of the part, from the PART LIST on
page 14. The number after the dash indicates the

quantity needed for assembly. Note: Some small
parts may have been pre-attached. If a part is not
in the parts bag, check to see if it has been pre-
attached.

3/8" Button Head

Screw (65)Ñ5

3/8" Lock Washer (66)Ñ3

3/8" Nylon Locknut (85)Ð2

#8 x 1/2" Screw (64)Ð6

(packaged with console)

5/8" Washer (59)Ñ2

/4" Spacer (58)Ñ2

5/8" Push Nut (60)Ñ4*

5/16" Nylon Jam Nut (62)Ð2

3/8" x 1 3/4" Bolt (84)Ð2

3/8" Flange Nut (88)Ð2

5/16" x 1 3/4" Carriage

Bolt (61)Ð2

*Extra 5/8Ó Push Nuts may be included
