Ryobi HP1830M - Manual (Page 7)

Page 7
SPECIFICATIONS
Chuck ............................................................................................................................................. 1/2 in. (13 mm) Keyless
Motor ................................................................................................................................................................... 18 Volt DC
Switch ........................................................................................................................................................... Variable Speed
Gear Train ............................................................................................................................................................... 3 Speed
No Load Speed ............................................................................................................................. 0-300/0-700/0-2000/min.
Hammer Speed .................................................................................................................. 0-4800/0-11,200/0-32,000 BPM
Clutch ................................................................................................................................................................ 24 Positions
Charger Input .................................................................................................................................... 120 V, 60 Hz, AC only
Charge Rate ............................................................................................................................................................... 1 Hour
Maximum Torque .................................................................................................................................................. 480 in./lb.
UNPACKING
INSTRUCTIONS
This Cordless Hammer Drill has been shipped completely
assembled.
■ Carefully remove the tool and the accessories from the
box.
■ Make sure that all items listed in the packing list are
included.
■ Inspect the tool carefully to be sure no breakage or
damage occurred during shipping.
■ Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the tool.
■ If any parts are damaged or missing, please call 1-800-
525-2579 for assistance.
PACKING LIST
Cordless Hammer Drill
2 batteries
Charging System
2 Bits
Operator's Manual
WARNING:
If any parts are missing do not operate this tool until the
missing parts are replaced. Failure to do so could result
in possible serious personal injury.
WARNING:
This tool should never be connected to a power supply
when you are assembling parts, making adjustments,
cleaning, performing maintenance, or when the tool is
not in use. Disconnecting the tool will prevent accidental
starting that could cause serious injury.
You may use the cordless hammer drill for the purposes listed below:
„ Hammer drilling in concrete, brick, or other masonry.
„ Drilling in wood.
„ Drilling in ceramics, plastics, fiberglass, and laminates.
„ Drilling in both soft and hard metals.
„ Driving screws with screwdriver bits, using driving accessories.
„ Mixing paint.
APPLICATIONS
