Revox V 219 User Manual
Page 5
Quick-reference description
[1] LED - Dimly lit: STANDBY
- Brightly lit: Normal operation
- Flashing slowly: IR command
reception
- Flashing rapidly: Maximum setting
[2]
IR receiver window
[3] SPEAKER RIGHT
Right-hand speaker
[4] SPEAKER LEFT
Left-hand speaker
[5] PRE-OUT (V 209)
Pre-amplified output
[6] AC POWER
Mains connection
[7] EXTERNAL IR
External
infrared
signal receiver
[8] AUDIO/DATA
BUS
Connection to the
multiroom bus
[9] AUX INPUT L/R
Input for local audio
source
Description
[1] LED - brille faiblement: STANDBY
- brille fortement: service normal
- clignote lentement: réception dune
commande IR
- clignote rapidement: réglage à la
butée
[2]
fenêtre de réception IR
[3] SPEAKER RIGHT
haut-parleur droit
[4] SPEAKER LEFT
haut-parleur gauche
[5] PRE-OUT (V 209)
Sortie pré-amplifica-
teur
[6] AC POWER
raccord réseau
[7] EXTERNAL IR
récepteur IR externe
[8] AUDIO/DATA BUS
raccordement
au
Multiroom Bus
[9] AUX INPUT L/R
entrée pour source
audio locale
Kurzbeschreibung
[1] LED - leuchtet schwach: STANDBY
- leuchtet stark: Normalbetrieb
- blinkt langsam: Empfang eines IR-Be-
fehls
- blinkt schnell: Einstellung am An-
schlag
[2]
IR - Empfangsfenster
[3] SPEAKER RIGHT
Lautsprecher rechts
[4] SPEAKER LEFT
Lautsprecher links
[5] PRE-OUT (V 209)
Vorverstärker-Aus-
gang
[6] AC POWER
Netzanschluss
[7] EXTERNAL IR
Externer IR-Empfän-
ger
[8] AUDIO/DATA
BUS
Anschluss an den
Multiroom-Bus
[9] AUX INPUT L/R
Eingang für eine lokale
Audio-Quelle
Front view Elegance Multiroom Bass
Rear view V219 / Elegance Multiroom Bass
[8]
[7]
[4]
[3]
[6]
[9]
[8]
[7]
[6]
[9]
[5]
Rear view V209
Front view V219
[1]
[2]
