Wireless Adapter RNX-N1/N1MAC User Manual
70
6. APPENDIX B – SPECIFICATIONS
Data Rates
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48,
54, 72, 84, 150 and 300Mbps (300 Rx
PHY rate; 150Mbps Tx PHY support)
Standards / Compliance
IEEE802.3, IEEE802.3u, IEEE802.11b,
IEEE802.11g, 802.11n (2.0)
Regulation Certifications
FCC Part 15, ETSI 300/328/CE
Operating Voltage
5 V ± 0.25V
Status LEDs
POWER / LINK
Drivers
Windows 2000/XP/Vista
MAC OS 10.3/10.4/10.5
RF Information
Frequency Band
U.S., Europe and Japan product
covering 2.4 to 2.484 GHz,
programmable for different country
regulations
Media Access Protocol
Carrier Sense Multiple Access with
Collision Avoidance (CSMA/CA)
Modulation Technology
802.11g: OFDM (64-QAM, 16-QAM,
QPSK, BPSK)
802.11b: DSSS (DBPSK, DQPSK, CCK)
Operating Channels
11 for North America, 14 for Japan, 13
for Europe
Receive Sensitivity (Typical)
• 2.412~2.472G(IEEE802.11b) (1Rx)
-91dBm @ 1Mbps
-87dBm @ 11Mbps
• 2.412~2.472G(IEEE802.11g) (2Rx)
-90dBm @ 6Mbps
-75dBm @ 54Mbps
• 2.412~2.472G(IEEE802.11N) (2Rx)
-88 dBm MCS 8
-65 dBm MCS 15
Available transmit power
• 2.412~2.472G(IEEE802.11b)
18dBm @1~11Mbps
• 2.412~2.472G(IEEE802.11g)
15 dBm @6Mbps
14 dBm @54Mbps
• 2.412~2.472G(IEEE802.11N)
15dBm
Antenna Configuration
2T2R Mode
Networking
Topology
Ad-Hoc, Infrastructure
Security
WPA/WPA2 (AES, 64,128-WEP with
shared-key authentication)
Cisco CCS V1.0, V2.0 and V3.0
compliant
Physical
Form Factor
USB 2.0/1.1
Dimensions (HxWxD)
77(L) mm x 23.5(W) mm x 11(H) mm
Weight
40 g/ 1.5oz
Environmental
Temperature Range
Operating: 0°C to 50°C
Storage: -10°Cto 75°C
Humidity (non-condensing)
5%~95% Typical
Package Contents
• One Wireless-N USB Dongle—RNX-
N1/N1MAC
• One CD-ROM with User’s Manual and
Drivers
• One FLEX USB cable (15cm)
• One Flexible Stainless Steel USB 2.0
Extended Connector
